Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Allen‑Bradley 1756‑OB16 ControlLogix Digital DC Output Module |
| Module Type | Digital DC output module (diagnostic/sourcing outputs) |
| Series | ControlLogix 1756 I/O family |
| Number of Outputs | 16 discrete DC output channels (sourcing) |
| Output Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Output Current per Point | Up to 1 A per channel (max) |
| Total Output Current | ~8 A per module (max) |
| Output Type | Sourcing DC outputs with status LEDs |
| Isolation Voltage | ~250 V continuous (outputs‑to‑backplane & group‑to‑group) |
| Backplane Current (5.1 VDC) | ~250 mA |
| Backplane Current (24 VDC) | ~2 mA |
| Power Dissipation | ~3.3 – 4.1 W @ 60 °C |
| Output Delay Time | Typically ~1 ms (OFF→ON) |
| Operating Temperature Range | 0 °C to 60 °C |
| Storage Temperature Range | −40 °C to 85 °C |
| Relative Humidity (Non‑condensing) | 5 % to 95 % |
| Connection Type | Removable terminal block (user defined) |
| Mounting | ControlLogix chassis slot |
| Dimensions (H × W × D) | ~54 mm × ~38 mm × ~111 mm (standard 1756 module footprint) (typical physical size) |
| Weight | ~0.36 kg (estimated typical) |
FAQ
FAQ
Q1: What is the 1756‑OB16 module used for?
It provides 16 DC digital output channels for driving field devices such as relays and solenoids in a ControlLogix system.
Q2: What DC voltage range does this output module support?
It supports an operating range of approximately 10–31.2 V DC, with a nominal of 24 V DC.
Q3: How much current can each output deliver?
Each output channel can provide up to about 1 A maximum.
Q4: What is the total current capacity of the module?
The module can supply up to about 8 A in total across all outputs.
Q5: Is there electrical isolation on the module?
Yes, there is continuous isolation of roughly 250 V between outputs and the backplane as well as between output groups.
Q6: What kind of feedback or status does the module provide?
Status LEDs indicate the on/off state of each output channel.
Q7: What environmental conditions can the module operate in?
It operates normally from 0 °C to 60 °C and can be stored from −40 °C to 85 °C with up to 95 % non‑condensing humidity.
Q8: What are the approximate physical size and weight?
It follows the standard ControlLogix I/O module size (~54×38×111 mm) and weighs around ~0.36 kg (typical estimate).
