Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley 1756-PB75K |
| Product Type | ControlLogix DC Power Supply Module |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Series | ControlLogix 1756 |
| Input Voltage | 18–32 V DC (nominal 24 V DC) |
| Input Power | Approx. 95 W |
| Output Power | Max. 75 W |
| Backplane Output | 5V DC @ 13A, 3.3V DC @ 4A, 1.2V DC @ 1.5A, 24V DC @ 2.8A |
| Inrush Current | Approx. 30 A |
| Hold-up Time | ~40 ms (at 24 V DC) |
| Redundancy Support | No |
| Mounting Type | ControlLogix chassis mount |
| Chassis Compatibility | 1756 series chassis (A4, A7, A10, A13, A17) |
| Isolation Voltage | Reinforced insulation (input to backplane) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Enclosure Type | Open-style module |
| Cooling Method | Natural convection (chassis airflow) |
| Dimensions | Approx. 145 × 140 × 112 mm |
| Weight | Approx. 0.95–1.1 kg |
| Certifications | CE, UL, CSA, KC, RCM |
FAQ
FAQ
Q1: What is the 1756-PB75K used for?
The 1756-PB75K is a ControlLogix DC power supply module that provides regulated backplane power for ControlLogix chassis systems.
Q2: What input power does it require?
It operates on a 24 V DC nominal input range of 18–32 V DC.
Q3: What is the output capacity of this module?
It delivers up to 75 W of total output power to the chassis backplane.
Q4: Which voltages does it supply to the system?
It supplies multiple regulated rails including 5V DC, 3.3V DC, 1.2V DC, and 24V DC for system operation.
Q5: Is the 1756-PB75K redundant?
No, this model does not support redundant power configurations.
Q6: What chassis is compatible with this power supply?
It is compatible with standard ControlLogix 1756 chassis such as 1756-A4 through 1756-A17.
Q7: What is the typical application of this module?
It is used in industrial automation systems to power ControlLogix PLC processors, I/O modules, and communication modules.
Q8: Can it be used in harsh environments?
Yes, it is designed for industrial environments, but it must be installed inside a ControlLogix chassis and control cabinet.
