Technical Specifications
| Specification | Parameter |
|---|---|
| Part Number / Model | 1757-SRM |
| Module Type | System Redundancy Module |
| System Compatibility | ProcessLogix / ControlLogix systems |
| Function | Enables controller redundancy by synchronizing two controllers in separate chassis |
| Slot Requirement | 2 chassis slots |
| Backplane Current | 0.160 A @ 24 V DC |
| Power Dissipation | ~11.28 W (max) |
| Thermal Dissipation | ~38.49 BTU/hr (max) |
| Communication Type | Fiber-optic (multi-mode) |
| Connector Type | SC connector |
| Fiber Specification | 62.5/125 µm multi-mode fiber |
| Wavelength | 1300 nm |
| Channels | 1 (Transmit & Receive) |
| Compatible Cables | 1757-SRC1, SRC3, SRC10, SRC50, SRC100 |
| Supported Controllers | Logix 5560 series |
| Mounting | ControlLogix chassis |
| Operating Temperature | 0–60 °C |
| Enclosure Type | Open-style (no enclosure) |
| Dimensions (L × W × H) | 145 mm × 70 mm × 140 mm |
| Weight | ~0.45 kg |
FAQ
FAQ
Q1: What is the main function of the 1757-SRM?
It enables controller redundancy by synchronizing two PLC systems, ensuring continuous operation if one fails.
Q2: How many modules are required for redundancy?
Two modules are required—one installed in each chassis.
Q3: What type of communication does it use?
It uses fiber-optic communication for fast and reliable synchronization between controllers.
Q4: What cables are compatible with this module?
It supports fiber cables such as 1757-SRC1, SRC3, SRC10, SRC50, and SRC100.
Q5: How many slots does it occupy?
The module requires two slots in the ControlLogix chassis.
Q6: What controllers can be used with it?
It is typically used with Logix 5560 series controllers.
Q7: What is the operating temperature range?
It operates in industrial environments from 0 °C to 60 °C.
Q8: What are the physical size and weight?
The module measures approximately 145 mm × 70 mm × 140 mm and weighs about 0.45 kg.
