Allen Bradley 1761-CBL-AP00 MicroLogix RS-232 Communication Cable

FAQ

Q1: What is the purpose of the 1761-CBL-AP00 cable?
The 1761-CBL-AP00 is an RS-232 communication cable used for programming and communication between a PC and Allen-Bradley MicroLogix controllers.

Q2: What connectors are used on this cable?
It uses an 8-pin Mini-DIN connector on one end and a DB9 female connector on the other.

Q3: What is the cable length?
The cable length is 0.5 meters (1.5 feet).

Q4: Which PLC models are compatible with this cable?
It is commonly used with MicroLogix 1000, 1200, and 1500 series PLCs.

Q5: Is this cable used for programming or Ethernet communication?
The cable is for serial RS-232 communication and PLC programming, not Ethernet networking.

Q6: Can this cable be used with modern USB-only laptops?
Yes, but a compatible USB-to-serial adapter is typically required because the cable terminates in a DB9 serial connector.

Q7: What is the difference between 1761-CBL-AP00 and 1761-CBL-PM02?
The AP00 uses an 8-pin Mini-DIN to DB9 configuration mainly for MicroLogix serial communication, while the PM02 is another programming cable variant with different wiring/application requirements. PLC community discussions frequently distinguish them during troubleshooting.

Q8: Is the 1761-CBL-AP00 still available?
Yes. Rockwell Automation currently lists the 1761-CBL-AP00 lifecycle status as “Active Mature.”
