Technical Specifications
| Parameter | Specification |
|---|---|
| Product | 1763-L16DWD – Allen‑Bradley MicroLogix 1100 16‑Point PLC Controller |
| Controller Type | MicroLogix 1100 integrated programmable controller with onboard I/O and communications support |
| Power Supply Input | 12–24 V DC (Class 2 SELV) |
| Digital Inputs | 10 × 12/24 V DC sink/source (including high‑speed channels) |
| Analog Inputs | 2 × voltage analog inputs (0–10 V DC) |
| Digital Outputs | 6 × relay outputs (isolated; AC/DC switching) |
| Communication Ports | 1 × Ethernet/IP; 1 × isolated RS‑232/RS‑485 combo port (DF1, DH‑485, Modbus RTU/ASCII) |
| Memory | 8 KB user program memory |
| Operating Temperature | –20 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Humidity (Operating) | 5 % to 95 % non‑condensing |
| Relay Output Load Ratings | Up to 125 V DC or 120–240 VAC; turn‑on/off time ~10 ms |
| Scan/Processing | Standard MicroLogix processing with integrated LCD and keypad |
| Mounting | DIN rail or panel mount |
| Weight | ~0.9 kg (approx. 2.0 lbs) |
| Dimensions (H × W × D) | 90 mm × 110 mm × 87 mm |
| Lifecycle Status | Discontinued by manufacturer (as of April 30 2022) |
FAQ
FAQ
Q1. What type of controller is the 1763‑L16DWD?
It is a MicroLogix 1100 series programmable logic controller with integrated I/O.
Q2. What power supply does the 1763‑L16DWD require?
It uses a 12–24 V DC Class 2 SELV power input.
Q3. How many I/O points does this controller provide?
It has a total of 16 points: 10 digital inputs, 2 analog inputs, and 6 relay outputs.
Q4. What communication options are available on this model?
It includes Ethernet/IP and an isolated serial port (RS‑232/RS‑485) supporting standard PLC protocols.
Q5. What is the memory capacity of this PLC?
The controller provides 8 KB of user memory for programs and data.
Q6. What are the environmental operating limits?
It operates between –20 °C and 60 °C with 5 %–95 % non‑condensing humidity.
Q7. What are the dimensions and weight of the 1763‑L16DWD?
Dimensions are 90 mm × 110 mm × 87 mm and weight is about 0.9 kg.
Q8. Is the 1763‑L16DWD still actively manufactured?
No, this model has been discontinued by Rockwell Automation.
