Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | MicroLogix 1500 |
| Model Number | 1764-24BWA/B |
| Product Type | PLC Base Controller |
| Power Supply | 85 to 265V AC, 47 to 63 Hz |
| Digital Inputs | 12 Inputs |
| Input Type | 24V DC Sink/Source |
| High-Speed Inputs | 4 High-Speed Inputs |
| Digital Outputs | 12 Relay Outputs |
| Output Voltage Range | 24-125V DC / 120-240V AC |
| Communication Port | RS-232 Serial Port |
| Maximum Expansion I/O | Up to 512 I/O Points |
| Mounting Type | DIN Rail or Panel Mount |
| Compatible Processors | 1764-LSP, 1764-LRP |
| Compatible Memory Modules | 1764-MM1, MM2, MM3, MM4 |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 85°C |
| Operating Humidity | 5% to 95% Non-Condensing |
| Power Consumption | 88 VA |
| Operating Frequency | 0 to 20 kHz |
| Certifications | UL, CE, CSA, Class I Division 2 |
| Dimensions | Approx. 168 x 138 x 87 mm |
| Weight | Approx. 0.89 – 1.0 kg |
| Lifecycle Status | Discontinued |
| Typical Applications | Machine Control, Industrial Automation, Material Handling |
FAQ
FAQ
Q1: What is the Allen-Bradley 1764-24BWA/B used for?
A1: The 1764-24BWA/B is a MicroLogix 1500 PLC base controller designed for industrial automation applications such as conveyor systems, packaging machines, and process control.
Q2: Does the 1764-24BWA/B include built-in I/O?
A2: Yes. The controller includes 12 digital inputs and 12 relay outputs integrated into the base unit.
Q3: What type of power supply does the 1764-24BWA/B require?
A3: The unit operates with an AC power supply ranging from 85 to 265V AC at 47 to 63 Hz.
Q4: Can the 1764-24BWA/B support expansion modules?
A4: Yes. The controller supports expansion I/O modules and can handle up to 512 I/O points when expanded.
Q5: Which processors are compatible with this base unit?
A5: The 1764-24BWA/B is compatible with Allen-Bradley 1764-LSP and 1764-LRP processors.
Q6: What communication interface is available on this controller?
A6: The unit includes an RS-232 serial communication port for programming and device communication.
Q7: Is the 1764-24BWA/B still in production?
A7: No. Rockwell Automation has officially discontinued this model, but refurbished and surplus units are still available in the market.
Q8: What mounting options are supported for the 1764-24BWA/B?
A8: The controller supports both DIN rail mounting and panel mounting for flexible installation in industrial cabinets.
