Technical Specifications
| Parameter | Specification |
|---|---|
| Product | 1769-ECR CompactLogix Right End Cap Module |
| Module Type | Compact I/O right-side termination module |
| Function | Terminates the right end of a 1769 Compact I/O bank to maintain proper backplane communication integrity |
| Compatibility | 1769 CompactLogix / Compact I/O systems |
| Installation Position | Right-most slot of I/O expansion bank |
| Electrical Requirement | No external power required |
| Backplane Current Draw | 0 A |
| Communication Role | Passive termination device (no data processing or communication) |
| Indicators | None |
| Mounting | Inserts into standard 1769 I/O slot |
| Material | Industrial-grade plastic housing |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Humidity (Operating) | 5 % to 95 % non-condensing |
| Shock (Operating) | 30 g |
| Vibration (Operating) | 5 g @ 10–500 Hz |
| Weight | ~0.02 kg |
| Dimensions (H × W × D) | 118 mm × 35 mm × 87 mm |
| Application | End termination for Compact I/O expansion systems |
FAQ
FAQ
Q1. What is the 1769-ECR used for?
It is used to terminate the right side of a 1769 Compact I/O expansion bank to ensure proper system communication.
Q2. Is the 1769-ECR an active module?
No, it is a passive termination device and does not process any data.
Q3. Does it require power to operate?
No, it does not require any external or backplane power.
Q4. Where is the 1769-ECR installed?
It is installed in the right-most slot of the Compact I/O bank.
Q5. What happens if the end cap is missing?
The system may experience communication faults or I/O module errors.
Q6. Can it be reused?
Yes, it can be reused if it is undamaged and still mechanically intact.
Q7. What are its dimensions and weight?
It measures approximately 118 mm × 35 mm × 87 mm and weighs about 0.02 kg.
Q8. What environments is it suitable for?
It is designed for industrial environments operating from 0 °C to 60 °C with 5 %–95 % non-condensing humidity.
