Technical Specifications
| Parameter | Specification |
|---|---|
| Product | 1769-HSC CompactLogix High-Speed Counter Module |
| Module Type | High-speed counter input module |
| Function | Counts high-speed pulse signals for position, speed, and event measurement |
| Compatibility | 1769 CompactLogix / Compact I/O systems |
| Input Channels | 2 independent high-speed counter channels |
| Input Types | Sink/source, differential (depending on wiring configuration) |
| Maximum Input Frequency | Up to 1 MHz (depending on mode and configuration) |
| Counter Modes | Up/down, frequency measurement, pulse counting, event counting |
| Input Voltage Range | 5–30 V DC (typical industrial input range) |
| Backplane Current Draw | ~0.8 A @ 5 V DC |
| Power Consumption | ~4–5 W |
| Isolation Voltage | 30 V continuous functional isolation |
| Status Indicators | LED indicators for module and channel status |
| Configuration | Software configurable via Logix controller |
| Mounting | DIN rail or panel mount (1769 backplane slot) |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Humidity (Operating) | 5 % to 95 % non-condensing |
| Shock (Operating) | 30 g |
| Vibration (Operating) | 5 g @ 10–500 Hz |
| Weight | ~0.3 kg |
| Dimensions (H × W × D) | 118 mm × 35 mm × 87 mm |
| Application | High-speed pulse counting for encoders, flow meters, and motion systems |
FAQ
FAQ
Q1. What is the 1769-HSC used for?
It is used to count high-speed digital pulses from devices such as encoders, flow sensors, and motion systems.
Q2. How many channels does the module support?
It supports two independent high-speed counter input channels.
Q3. What is the maximum counting speed?
It can handle input frequencies up to approximately 1 MHz depending on configuration and signal type.
Q4. What types of signals can it read?
It supports sink/source and differential pulse signals depending on wiring setup.
Q5. Can it measure frequency as well as count pulses?
Yes, it supports frequency measurement, pulse counting, and event-based counting modes.
Q6. How is the module configured?
It is configured through the CompactLogix controller using Rockwell programming software.
Q7. What are the physical dimensions and weight?
It measures about 118 mm × 35 mm × 87 mm and weighs approximately 0.3 kg.
Q8. What environments is it suitable for?
It operates in industrial environments from 0 °C to 60 °C with 5 %–95 % non-condensing humidity.
