Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | CompactLogix 5370 L2 |
| Model Number | 1769-L27ERM-QBFC1B |
| Product Type | Programmable Automation Controller (PAC) |
| Controller Family | CompactLogix |
| User Memory | 1 MB |
| Embedded Digital Inputs | 16 x 24V DC Inputs |
| Embedded Digital Outputs | 16 x 24V DC Outputs |
| Embedded Analog Inputs | 4 Analog Inputs |
| Embedded Analog Outputs | 2 Analog Outputs |
| Input Type | Sink/Source DC |
| Output Type | Source DC Outputs |
| Communication Ports | 2 x EtherNet/IP Ports, 1 x USB Port |
| Ethernet Topologies | Linear, Star, Device Level Ring (DLR) |
| Supported Ethernet Nodes | Up to 16 EtherNet/IP Nodes |
| Motion Control Support | Up to 2 Ethernet/IP Motion Axes |
| Expansion Capability | Supports up to 8 Compact I/O Modules |
| Programming Software | Studio 5000 Logix Designer |
| Programming Languages | Ladder Logic, Structured Text, Function Block, SFC |
| Power Supply | 24V DC |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Isolation Voltage | 50V Continuous |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Dimensions | Approx. 140 x 118 x 95 mm |
| Weight | Approx. 0.95 kg |
| Certifications | UL, CE, CSA, Class I Division 2 |
| Typical Applications | Packaging Systems, OEM Machines, Motion Control, Industrial Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 1769-L27ERM-QBFC1B used for?
A1: The 1769-L27ERM-QBFC1B is a CompactLogix 5370 programmable automation controller designed for machine automation, motion control, packaging systems, and industrial process applications.
Q2: How many built-in inputs and outputs does the 1769-L27ERM-QBFC1B include?
A2: The controller includes 16 digital DC inputs, 16 digital DC outputs, 4 analog inputs, and 2 analog outputs.
Q3: Does the 1769-L27ERM-QBFC1B support Ethernet communication?
A3: Yes. The controller features dual EtherNet/IP ports supporting Linear, Star, and Device Level Ring (DLR) network topologies.
Q4: Can the 1769-L27ERM-QBFC1B support motion control applications?
A4: Yes. The controller supports up to two EtherNet/IP motion axes for integrated motion control applications.
Q5: Which programming software is compatible with the 1769-L27ERM-QBFC1B?
A5: The controller is programmed using Studio 5000 Logix Designer software from Rockwell Automation.
Q6: Does the 1769-L27ERM-QBFC1B support expansion modules?
A6: Yes. The controller supports up to eight Compact I/O expansion modules for increased system flexibility.
Q7: What type of power supply is required for the 1769-L27ERM-QBFC1B?
A7: The controller operates using a 24V DC power supply commonly used in industrial automation systems.
Q8: Is the 1769-L27ERM-QBFC1B suitable for industrial environments?
A8: Yes. The controller is designed for industrial automation environments and includes certifications such as UL, CE, CSA, and Class I Division 2.
