Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | CompactLogix 5370 L1 |
| Model Number | 1769-L18ER-BB1B |
| Product Type | Programmable Automation Controller (PAC) |
| Controller Family | CompactLogix |
| User Memory | 512 KB |
| Non-Volatile Memory | 1 GB SD Card Included |
| Embedded Digital Inputs | 16 x 24V DC Inputs |
| Embedded Digital Outputs | 16 x 24V DC Outputs |
| Input Type | Sink Inputs |
| Output Type | Source Outputs |
| Communication Ports | 2 x EtherNet/IP Ports, 1 x USB Port |
| Ethernet Topologies | Linear, Star, Device Level Ring (DLR) |
| Ethernet Nodes Supported | Up to 8 EtherNet/IP Nodes |
| Expansion Capability | Supports up to 8 POINT I/O Modules |
| Programming Software | Studio 5000 Logix Designer |
| Programming Languages | Ladder Logic, Structured Text, Function Block, SFC |
| Power Supply | 24V DC |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Isolation Voltage | 50V Continuous |
| Dimensions | Approx. 131.6 x 100 x 105 mm |
| Weight | Approx. 1.36 kg |
| Certifications | UL, CE, CSA, Class I Division 2 |
| Typical Applications | Packaging Machines, Material Handling, OEM Automation Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 1769-L18ER-BB1B used for?
A1: The 1769-L18ER-BB1B is a CompactLogix 5370 L1 programmable automation controller designed for compact industrial automation systems, including packaging, material handling, and machine control applications.
Q2: How much memory does the 1769-L18ER-BB1B provide?
A2: The controller includes 512 KB of user memory and comes with a 1 GB SD card for non-volatile storage.
Q3: How many built-in inputs and outputs are included?
A3: The controller features 16 embedded 24V DC digital inputs and 16 embedded 24V DC digital outputs.
Q4: Does the 1769-L18ER-BB1B support Ethernet communication?
A4: Yes. The controller includes dual EtherNet/IP ports that support Linear, Star, and Device Level Ring (DLR) network topologies.
Q5: Can expansion I/O modules be connected to the 1769-L18ER-BB1B?
A5: Yes. The controller supports up to eight 1734 POINT I/O expansion modules for increased system flexibility.
Q6: Which programming software is compatible with the 1769-L18ER-BB1B?
A6: The controller is programmed using Studio 5000 Logix Designer software from Rockwell Automation.
Q7: What mounting methods are supported for the 1769-L18ER-BB1B?
A7: The controller supports both DIN rail mounting and panel mounting for industrial cabinet installation.
Q8: Is the 1769-L18ER-BB1B suitable for industrial environments?
A8: Yes. The controller is designed for industrial automation environments and includes certifications such as UL, CE, CSA, and Class I Division 2.
