Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Compact GuardLogix 5370 |
| Model Number | 1769-L33ERMS |
| Product Type | Safety Programmable Automation Controller (PAC) |
| Controller Family | Compact GuardLogix |
| Standard User Memory | 2 MB |
| Safety Memory | 1 MB |
| Embedded I/O | None |
| Communication Ports | 2 x EtherNet/IP Ports, 1 x USB Port |
| Ethernet Topologies | Linear, Star, Device Level Ring (DLR) |
| Supported Ethernet Nodes | Up to 16 EtherNet/IP Nodes |
| Motion Control Support | CIP Motion |
| Communication Protocols | EtherNet/IP, CIP Safety |
| Expansion Capability | Supports up to 16 Compact I/O Modules |
| Supported Expansion Banks | Up to 3 Banks |
| Programming Software | Studio 5000 Logix Designer |
| Programming Languages | Ladder Logic, Structured Text, Function Block, SFC |
| Power Supply Requirement | Requires 1769 Power Supply |
| Isolation Voltage | 30V Continuous |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Ethernet Speed | 10/100 Mbps |
| USB Interface | USB 2.0 |
| Dimensions | Approx. 118 x 55 x 105 mm |
| Weight | Approx. 0.32 – 0.40 kg |
| Certifications | UL, CE, ATEX, ODVA, CSA |
| Lifecycle Status | End of Life |
| Replacement Model | 5069-L320ERMS3 |
| Typical Applications | Machine Safety, Motion Control, Industrial Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 1769-L33ERMS used for?
A1: The 1769-L33ERMS is a Compact GuardLogix safety controller designed for industrial automation systems requiring both standard control and integrated safety functions.
Q2: How much memory does the 1769-L33ERMS provide?
A2: The controller includes 2 MB of standard user memory and 1 MB of dedicated safety memory.
Q3: Does the 1769-L33ERMS include built-in I/O?
A3: No. The controller requires external 1769 Compact I/O modules for system expansion and field device connectivity.
Q4: What communication interfaces are available on the 1769-L33ERMS?
A4: The controller includes dual EtherNet/IP ports and one USB communication port for programming and industrial networking.
Q5: Does the 1769-L33ERMS support safety communication protocols?
A5: Yes. The controller supports CIP Safety over EtherNet/IP for integrated machine safety applications.
Q6: Which programming software is compatible with the 1769-L33ERMS?
A6: The controller is programmed using Studio 5000 Logix Designer software from Rockwell Automation.
Q7: Is the 1769-L33ERMS suitable for motion control applications?
A7: Yes. The controller supports CIP Motion functionality for coordinated motion control applications in industrial systems.
Q8: Is the 1769-L33ERMS still available from Rockwell Automation?
A8: No. Rockwell Automation has announced the 1769-L33ERMS as an End-of-Life product, and the recommended replacement model is the 5069-L320ERMS3.
