Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PLC-5 1771 I/O |
| Model Number | 1771-OVN |
| Product Type | DC Digital Output Module |
| Output Channels | 32 Outputs |
| Output Voltage Range | 10 to 60V DC |
| Nominal Output Voltage | 24V DC |
| Output Type | Source Output |
| Current per Output | 0.5 A |
| Maximum Current per Module | 8 A |
| Surge Current | 2 A for 10 ms |
| Signal Delay (ON/OFF) | Approx. 0.1 ms |
| Backplane Current Draw | Approx. 900 mA at 5V DC |
| Isolation Voltage | 1500V AC RMS |
| Power Dissipation | Approx. 15.5 W |
| Compatible Chassis | 1771-A1B to 1771-A4B I/O Chassis |
| Compatible Wiring Arm | 1771-WN |
| Addressing Modes | 1/2 Slot and 1 Slot Addressing |
| Status Indicators | 32 Red LED Indicators |
| Mounting Type | Rack Mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Wiring Category | Category 2 |
| Dimensions | Approx. 26 x 15 x 5 cm |
| Weight | Approx. 0.45 – 0.68 kg |
| Certifications | UL, CE, CSA, Class I Division 2 |
| Typical Applications | PLC Output Control, Industrial Automation, Machine Control |
FAQ
FAQ
Q1: What is the Allen-Bradley 1771-OVN used for?
A1: The 1771-OVN is a PLC-5 DC digital output module used for controlling field devices such as relays, solenoids, lamps, and other DC-operated industrial equipment.
Q2: How many output channels does the 1771-OVN provide?
A2: The module includes 32 DC digital output channels for high-density output applications.
Q3: What output voltage range does the 1771-OVN support?
A3: The module supports DC output voltages ranging from 10 to 60V DC, with a nominal operating voltage of 24V DC.
Q4: What type of outputs does the 1771-OVN use?
A4: The module uses sourcing DC outputs designed to provide current to connected field devices.
Q5: Which PLC systems are compatible with the 1771-OVN?
A5: The module is compatible with Allen-Bradley PLC-5 systems using 1771 I/O chassis platforms.
Q6: What wiring arm is required for the 1771-OVN?
A6: The module requires the Allen-Bradley 1771-WN field wiring arm for installation and field wiring connections.
Q7: Does the 1771-OVN include status indicators?
A7: Yes. The module includes 32 LED indicators for monitoring the status of each output channel.
Q8: What are the common applications of the 1771-OVN?
A8: Common applications include industrial machine control, conveyor systems, packaging equipment, process automation, and general-purpose PLC output control.
