Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Data Highway Communication Cards |
| Model Number | 1784-PCMK |
| Product Type | PCMCIA DH+/DH- Communication Card |
| Communication Networks | Data Highway Plus (DH+), Data Highway (DH) |
| Card Type | PCMCIA Type II |
| Communication Speed | 57.6 kbps, 115.2 kbps, 230.4 kbps |
| Network Connector | 8-Pin Mini-DIN Connector |
| Supported Media | Twinaxial DH+ Cable |
| Compatible Computers | Laptop and Portable PCs with PCMCIA Slot |
| Compatible Software | RSLinx, RSLogix 5, RSLogix 500 |
| Supported Operating Systems | Windows-Based Systems |
| LED Indicators | Communication and Network Status LEDs |
| Power Supply | Powered Through PCMCIA Slot |
| Isolation Voltage | 500V |
| Installation Type | Portable PC Communication Interface |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G Operating |
| Vibration Resistance | 2 G at 10 to 500 Hz |
| Certifications | UL, CE |
| Lifecycle Status | Discontinued |
| Dimensions | Approx. 119 x 54 x 16 mm |
| Weight | Approx. 0.11 – 0.13 kg |
| Typical Applications | PLC Programming, DH+ Networking, Industrial Communication |
FAQ
FAQ
Q1: What is the Allen-Bradley 1784-PCMK used for?
A1: The 1784-PCMK is a PCMCIA communication card used to connect laptops and portable computers to Allen-Bradley DH+ and DH industrial networks for PLC programming and diagnostics.
Q2: Which communication networks are supported by the 1784-PCMK?
A2: The card supports both Data Highway Plus (DH+) and Data Highway (DH) communication networks.
Q3: What type of computer slot is required for the 1784-PCMK?
A3: The module requires a PCMCIA Type II slot commonly found on older industrial laptops and portable computers.
Q4: What communication speeds are supported by the 1784-PCMK?
A4: The card supports communication speeds of 57.6 kbps, 115.2 kbps, and 230.4 kbps for DH+ networks.
Q5: Which Allen-Bradley software packages are compatible with the 1784-PCMK?
A5: The card works with software such as RSLinx, RSLogix 5, and RSLogix 500 for PLC communication and troubleshooting.
Q6: Is the 1784-PCMK still available from Rockwell Automation?
A6: No. The 1784-PCMK has been discontinued, although refurbished and surplus units remain available through industrial automation suppliers.
Q7: What are the common applications of the 1784-PCMK?
A7: Common applications include PLC programming, DH+ communication, industrial troubleshooting, factory automation support, and legacy Allen-Bradley network maintenance.
Q8: Does the 1784-PCMK require an external power supply?
A8: No. The card receives power directly from the host computer’s PCMCIA slot during operation.
