Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Human Interface Module (HIM) |
| Model | Allen-Bradley 20-HIM-A3 |
| Series | PowerFlex Architecture Class |
| Function | Local drive operation, monitoring, and parameter configuration |
| Compatible Drives | PowerFlex 70 / 700 / 700S / 700H / 700L / 7000 / 750 / 753 / 755 series |
| Display | LCD screen (alphanumeric) |
| Keypad Type | Full numeric keypad with navigation keys |
| Communication | DPI (Drive Peripheral Interface) |
| Power Supply | Powered by host drive (typically 12–24 V DC via drive interface) |
| Operating Temperature | 0 to 50 °C |
| Mounting Type | Handheld or panel/drive-mounted |
| Protection Rating | IP20 (panel-mounted versions may vary) |
| Dimensions (H × W × D) | 157 × 76 × 30 mm |
| Weight | ~0.13 kg |
FAQ
FAQ
Q1. What is the 20-HIM-A3 used for?
It is a Human Interface Module used to operate, configure, and monitor Allen-Bradley PowerFlex drives locally.
Q2. Which drives are compatible with 20-HIM-A3?
It works with PowerFlex 70, 700, 700S, 750, 753, and 755 series drives, among others.
Q3. What functions does it provide?
It allows parameter editing, drive start/stop control, fault diagnostics, and parameter copying (CopyCat function).
Q4. Does it support handheld use?
Yes, it can be used as a handheld device or mounted directly on a drive or panel.
Q5. What type of display does it have?
It uses an LCD display with full numeric keypad for navigation and parameter input.
Q6. How does it connect to the drive?
It connects via DPI (Drive Peripheral Interface), which is standard for PowerFlex drives.
Q7. What are its physical dimensions?
Its size is approximately 157 × 76 × 30 mm, making it compact and portable.
Q8. Is the 20-HIM-A3 still in production?
No, it has been discontinued and replaced by newer models such as the 20-HIM-A6.
