Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Kinetix 300 |
| Model Number | 2097-V33PR3 |
| Product Type | EtherNet/IP Indexing Servo Drive |
| Drive Function | Single-axis Servo Drive |
| Input Voltage | 80…264V AC |
| Nominal Voltage Class | 120/240V AC |
| Input Phase | 1-Phase or 3-Phase |
| Input Frequency | 48…62 Hz |
| Continuous Output Current | 5.7 A |
| Continuous Output Power | 1.0 kW |
| Peak Output Current | 17.9 A (0-pk) |
| Communication Protocol | EtherNet/IP |
| Motion Control Type | Indexing Motion |
| Safe Torque Off (STO) | Yes |
| Compatible Motors | MP-Series, TL-Series Servo Motors |
| Integrated Ethernet Port | RJ45 EtherNet/IP |
| Overvoltage Protection | 850V DC |
| Short-circuit Rating | 100,000 A RMS Symmetrical |
| Control Modes | PTO, Indexing, Analog Control, Ethernet/IP Motion |
| Mounting Type | Panel Mount |
| Cooling Method | Forced Air Cooling |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -10°C to 70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, cUL, KC, ODVA EtherNet/IP |
| Lifecycle Status | Discontinued |
| Discontinued Date | July 31, 2024 |
| Recommended Replacement | 2198-E1007-ERS |
| Actual Dimensions (H × W × D) | Approx. 190 × 69 × 185 mm |
| Actual Weight | Approx. 1.5 kg |
| Typical Applications | Packaging Machines, Indexing Tables, Conveyors, Servo Positioning Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 2097-V33PR3 used for?
A1: The 2097-V33PR3 is a Kinetix 300 EtherNet/IP indexing servo drive used for precise single-axis motion control in industrial automation applications.
Q2: What is the output rating of the 2097-V33PR3?
A2: The drive provides 1.0 kW continuous output power with a continuous output current of 5.7 A.
Q3: What input voltage does the 2097-V33PR3 support?
A3: The servo drive supports 80…264V AC input and can operate on either single-phase or three-phase power supplies.
Q4: Does the 2097-V33PR3 include Safe Torque Off functionality?
A4: Yes. The drive includes integrated Safe Torque Off (STO) safety functionality compliant with industrial machine safety requirements.
Q5: What communication protocol does the 2097-V33PR3 use?
A5: The drive communicates using EtherNet/IP through an integrated RJ45 Ethernet port.
Q6: What are the actual dimensions and weight of the 2097-V33PR3?
A6: The approximate dimensions are 190 × 69 × 185 mm (H × W × D), and the approximate weight is 1.5 kg.
Q7: Is the 2097-V33PR3 still manufactured?
A7: No. Rockwell Automation discontinued the 2097-V33PR3 effective July 31, 2024. The recommended replacement is the 2198-E1007-ERS servo drive.
Q8: What are common applications for the 2097-V33PR3?
A8: Common applications include packaging systems, indexing equipment, conveyors, automated assembly systems, and positioning applications requiring precise servo motion control.
