Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex 70 |
| Model Number | 20AC030A3AYNACC0 |
| Product Type | AC Variable Frequency Drive (VFD) |
| Drive Type | Adjustable Frequency AC Drive |
| Input Voltage | 480V AC |
| Input Phase | 3-Phase |
| Output Voltage | 0…480V AC |
| Output Phase | 3-Phase |
| Rated Output Current | 30 A |
| Normal Duty Power Rating | 15 kW / 20 HP |
| Heavy Duty Power Rating | 11 kW / 15 HP |
| Input Frequency | 48…63 Hz |
| Output Frequency Range | 0…400 Hz |
| Enclosure Rating | IP20 / NEMA Type Open |
| HIM Interface | Full Numeric LCD HIM Included |
| Communication Interface | Standard DPI Communication |
| EMC Filtering | No Internal Filter |
| Brake Transistor | Yes |
| Control Method | V/Hz, Sensorless Vector, and Vector Control |
| Mounting Type | Panel Mount |
| Cooling Method | Forced Air Cooling |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Active / Legacy Support Depending on Region |
| Actual Dimensions (H × W × D) | Approx. 400 × 250 × 230 mm |
| Actual Weight | Approx. 11.8 kg |
| Typical Applications | Conveyors, Pumps, Fans, Mixers, Packaging Equipment, Industrial Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 20AC030A3AYNACC0 used for?
A1: The 20AC030A3AYNACC0 is a PowerFlex 70 AC variable frequency drive designed for controlling three-phase AC motor speed and torque in industrial automation systems.
Q2: What is the power rating of the 20AC030A3AYNACC0?
A2: The drive is rated for 15 kW (20 HP) normal duty and 11 kW (15 HP) heavy duty operation.
Q3: What input voltage does the 20AC030A3AYNACC0 require?
A3: The drive operates on 480V AC three-phase input power.
Q4: Does the 20AC030A3AYNACC0 include a brake transistor?
A4: Yes. This model includes an internal brake transistor for dynamic braking applications.
Q5: Which control methods are supported by the 20AC030A3AYNACC0?
A5: The drive supports V/Hz control, sensorless vector control, and full vector motor control.
Q6: What operator interface is included with the 20AC030A3AYNACC0?
A6: The drive includes a full numeric LCD HIM (Human Interface Module).
Q7: What are the actual dimensions and weight of the 20AC030A3AYNACC0?
A7: The approximate dimensions are 400 × 250 × 230 mm (H × W × D) and the approximate weight is 11.8 kg.
Q8: What are common applications for the 20AC030A3AYNACC0?
A8: Common applications include conveyors, pumps, fans, mixers, packaging machinery, compressors, and industrial motor control systems.
