Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Variable Frequency Drive |
| Model | Allen-Bradley 20AC2P1A0AYNACC0 |
| Series | PowerFlex 70 |
| Function | Compact industrial motor speed and torque control drive |
| Input Voltage | 380–480 V AC, 3-phase |
| Input Frequency | 50/60 Hz |
| Output Current | 2.1 A |
| Output Power | 0.75 kW (Normal Duty) / 0.55 kW (Heavy Duty) |
| Frame Size | A Frame |
| Control Method | Sensorless Vector Control / Volts per Hertz |
| Communication | EtherNet/IP, DeviceNet, Modbus, PROFIBUS (optional depending on configuration) |
| EMC Filtering | Integrated EMC filter with common-mode choke |
| Brake Function | Brake IGBT installed |
| Brake Resistor | Not included |
| Control I/O | 6 digital inputs, 2 digital outputs, 2 analog inputs, 1 analog output |
| Protection Functions | Overvoltage, undervoltage, overcurrent, motor overload, ground fault |
| Efficiency | ~97.5% |
| Stop Modes | Coast, ramp, DC brake, fast stop, S-curve |
| Enclosure Rating | IP20 / NEMA Type 1 (panel mount) |
| Operating Temperature | 0 to 50 °C |
| Dimensions (H × W × D) | 225.7 × 122.4 × 179.8 mm |
| Weight | ~2.7 kg |
FAQ
FAQ
Q1. What is the 20AC2P1A0AYNACC0 used for?
It is a PowerFlex 70 AC drive used for controlling motor speed and torque in small industrial automation applications.
Q2. What is its power rating?
It is rated at 0.75 kW (normal duty) and 0.55 kW (heavy duty).
Q3. What type of input supply does it require?
It operates on a 380–480 V AC three-phase power supply.
Q4. Does it include braking capability?
Yes, it includes a built-in brake IGBT, but no internal brake resistor is included.
Q5. What communication protocols does it support?
It supports EtherNet/IP and other industrial networks depending on configuration options.
Q6. What is its enclosure type?
It is designed for IP20 / NEMA Type 1 panel mounting inside control cabinets.
Q7. What are its physical size and weight?
Its dimensions are approximately 225.7 × 122.4 × 179.8 mm and it weighs about 2.7 kg.
Q8. Is this model still in production?
It belongs to the PowerFlex 70 series, which is a legacy product line and is in end-of-life transition status.
