Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Variable Frequency Drive |
| Model | Allen-Bradley 20BC011A0AYNANC0 |
| Series | PowerFlex 700 |
| Function | Industrial AC motor speed and torque control drive |
| Input Voltage | 400 V AC, 3-phase |
| Input Frequency | 50/60 Hz |
| Output Current | 11.5 A |
| Output Power | 5.5 kW (Normal Duty) / 4.0 kW (Heavy Duty) |
| Frame Size | C Frame |
| Control Method | Sensorless Vector Control / V/Hz |
| Communication | EtherNet/IP, DeviceNet, PROFIBUS, Modbus (optional depending on configuration) |
| EMC Filter | Integrated EMC filter with common-mode choke |
| Brake Function | Brake IGBT installed (no internal brake resistor) |
| Control I/O | 6 digital inputs, 3 digital outputs, 2 analog inputs |
| Protection Functions | Overvoltage, undervoltage, overcurrent, motor overload, ground fault |
| Efficiency | ~97.5% |
| Stop Modes | Coast, ramp, DC brake, fast stop |
| Enclosure Rating | IP20 / NEMA Type 1 (panel mount) |
| Operating Temperature | 0 to 50 °C |
| Dimensions (H × W × D) | 300 × 185 × 179.8 mm |
| Weight | ~9 kg |
FAQ
FAQ
Q1. What is the 20BC011A0AYNANC0 used for?
It is a PowerFlex 700 AC drive used to control speed and torque of three-phase AC motors in industrial automation systems.
Q2. What is its power rating?
It is rated at 5.5 kW (normal duty) and 4.0 kW (heavy duty) with an output current of 11.5 A.
Q3. What type of input supply does it require?
It operates on a 400 V AC three-phase supply.
Q4. Does it include braking capability?
Yes, it includes a built-in brake IGBT, but requires an external braking resistor if braking energy needs to be dissipated.
Q5. What communication protocols are supported?
It supports EtherNet/IP, DeviceNet, Modbus, PROFIBUS, and other industrial networks depending on configuration.
Q6. What is the enclosure type?
It is an IP20 / NEMA Type 1 panel-mounted drive designed for installation inside electrical cabinets.
Q7. What are its physical dimensions and weight?
Its approximate dimensions are 300 × 185 × 179.8 mm and it weighs around 9 kg.
Q8. Is this model still in production?
No, the PowerFlex 700 series is discontinued and replaced by newer drive families.
