Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Variable Frequency Drive |
| Model | Allen-Bradley 20BC043A0AYNANC0 |
| Series | PowerFlex 700 |
| Function | Industrial AC motor speed and torque control drive |
| Input Voltage | 380–480 V AC, 3-phase |
| Nominal Voltage | 400 V AC |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0–460 V AC, 3-phase |
| Output Current | 43 A |
| Output Power | 22 kW (Normal Duty) / 18.5 kW (Heavy Duty) |
| Frame Size | Frame 3 |
| Control Method | Sensorless Vector Control / V/Hz |
| Communication | Optional (no module included by default) |
| EMC Filter | Integrated CE filter with common-mode choke |
| Brake Function | Built-in brake IGBT (no internal resistor) |
| Control I/O | Digital and analog I/O with 24 V control |
| Feedback | No feedback (open-loop) |
| Protection Functions | Overcurrent, overvoltage, undervoltage, motor overload, ground fault |
| Enclosure Rating | IP20 / NEMA Type 1 |
| Mounting Type | Panel mount |
| Operating Temperature | 0 to 50 °C |
| Dimensions (H × W × D) | ~300 × 250 × 150 mm |
| Weight | ~13.6–15 kg |
FAQ
FAQ
Q1. What is the 20BC043A0AYNANC0 used for?
It is a PowerFlex 700 AC drive used to control speed and torque of three-phase motors in industrial automation systems.
Q2. What is its power rating?
It delivers 22 kW in normal duty and 18.5 kW in heavy duty operation.
Q3. What input power does it require?
It operates on a 380–480 V AC three-phase supply, typically rated at 400 V.
Q4. Does it include braking capability?
Yes, it includes a built-in brake IGBT, but requires an external resistor for braking energy dissipation.
Q5. Does it come with a communication module?
No, this model does not include a communication module by default and requires optional add-ons if needed.
Q6. What control method does it use?
It supports sensorless vector control and V/Hz control for flexible motor operation.
Q7. What are its dimensions and weight?
Its approximate size is 300 × 250 × 150 mm, with a weight around 13.6–15 kg.
Q8. Is this model still available?
No, it has been discontinued and is now considered a legacy PowerFlex 700 product.
