Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Manufacturer |
Allen-Bradley |
|
Model |
|
|
Product Type |
Adjustable Frequency AC Drive |
|
Product Series |
PowerFlex 700, 20B |
|
Input Voltage |
480 VAC |
|
Input Phase |
3-phase |
|
Input Frequency |
60 Hz |
|
Rated Output Current |
248 A |
|
Normal-Duty Power Rating |
200 HP |
|
Heavy-Duty Power Rating |
150 HP |
|
Control Type |
Vector control |
|
Control I/O |
24V DC/AC I/O |
|
Human Interface Module (HIM) |
Blank cover; no HIM |
|
Feedback Option |
No feedback |
|
Communication Module |
None specified |
|
Brake IGBT |
Not included |
|
Internal Brake Resistor |
Not included |
|
EMC Filter |
Configuration-dependent; verify the unit nameplate |
|
Enclosure Rating |
IP20 / NEMA/UL Type 1 |
|
Frame Size |
Frame 6 |
|
Operating Temperature |
0–50°C, subject to rating and installation conditions |
|
Maximum Altitude |
1000 m without derating |
|
Relative Humidity |
5–95%, noncondensing |
|
Approximate Dimensions (H × W × D) |
850 × 403.9 × 275.5 mm (33.46 × 15.90 × 10.85 in), standard Frame 6 reference |
|
Approximate Net Weight |
72.57 kg (160 lb), reported for this catalog number |
|
Product Lifecycle |
Discontinued |
|
Typical Applications |
Pumps, fans, conveyors and industrial motor-speed control |
FAQ
FAQ
Q1: What is the Allen-Bradley 20BD248A0ANNANA0?
A: The 20BD248A0ANNANA0 is a PowerFlex 700 adjustable frequency AC drive designed to control the speed and operation of three-phase industrial motors.
Q2: What are the input voltage and output current ratings?
A: This drive is designed for a 480V AC supply and has a rated output current of 248 A. It is intended for compatible industrial motor-control applications.
Q3: What is the motor power rating of this drive?
A: The specified power ratings are 200 HP for normal-duty operation and 150 HP for heavy-duty operation. Final motor selection should account for load characteristics, operating conditions and applicable drive ratings.
Q4: What are the dimensions and weight of the 20BD248A0ANNANA0?
A: The reference dimensions for the corresponding Frame 6 configuration are approximately 850 × 403.9 × 275.5 mm (H × W × D). The reported weight is approximately 72.57 kg (160 lb). Confirm the exact mechanical drawing and unit configuration before installation.
Q5: Does this model include a Human Interface Module?
A: No. The listed configuration uses a blank cover instead of a built-in Human Interface Module. A compatible interface or programming tool may be required for configuration and diagnostics.
Q6: Does the drive include an internal braking resistor?
A: No. The specified configuration does not include an internal braking resistor or braking IGBT. External braking equipment may be required for applications involving rapid deceleration.
Q7: What should be considered when installing this drive?
A: Check the power supply, motor ratings, ventilation clearances, grounding, enclosure requirements and ambient conditions. The drive should be installed and commissioned according to the applicable manufacturer’s instructions.
Q8: Is the Allen-Bradley 20BD248A0ANNANA0 still available?
A: The PowerFlex 700 series has been discontinued. Remaining inventory and refurbished units may be available through industrial automation suppliers. Verify the catalog number, product condition, warranty and compatibility before purchasing.
