Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Series | PowerFlex 700 |
| Catalog Number | 20BP140A3ANNANC0 |
| Product Type | DC Input AC Drive |
| Input Voltage | 540 VDC, precharge |
| Input Phase | 3-phase |
| Output Current | 140 A |
| Normal-Duty Power | 75 kW |
| Heavy-Duty Power | 55 kW |
| Frame Size | Frame 5 |
| Enclosure | IP20 / NEMA/UL Type 1 |
| Human Interface | LCD display, full numeric keypad |
| Control Method | Vector control with 24 VDC I/O |
| Communication | No internal communication module |
| Feedback | No feedback option |
| Encoder Supply | 12 VDC, 250 mA |
| EMC Filter | EMC filter with common-mode choke |
| Brake IGBT | Without |
| Internal Brake Resistor | No |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Digital Inputs | 6 |
| Digital Outputs | 3 |
| Maximum Output Frequency | 420 Hz |
| Carrier Frequency | 2, 4, 8, or 10 kHz |
| Overload Capacity | 110% for 1 min; 150% for 3 s |
| Efficiency | 97.5% at rated current and nominal line voltage |
| Ambient Temperature | 0–50 °C for IP20 frames 5–6 |
| Dimensions (H × W × D) | Approx. 1574.8 × 609.6 × 450.7 mm* |
| Weight | Approx. 154.68 kg* |
| Country of Origin | USA |
FAQ
FAQ
Q1: What is the 20BP140A3ANNANC0?
It is an Allen-Bradley PowerFlex 700 DC-input AC drive intended for industrial motor speed and torque control.
Q2: What is the input voltage of this drive?
The drive is designed for a 540 VDC input with precharge.
Q3: What is the output rating?
It provides 140 A, with a 75 kW normal-duty and 55 kW heavy-duty rating.
Q4: Does this model have an internal communication module?
No. The 20BP140A3ANNANC0 is specified without an internal communication module.
Q5: Does it support encoder feedback?
No. This particular ANC0 configuration is specified with no feedback option. The drive family supports encoder functionality, but it should not be assumed to be installed on this exact catalog number.
Q6: Does the drive include braking hardware?
No. It has no brake IGBT and no internal brake resistor.
Q7: What operator interface is included?
The drive has an LCD display with a full numeric keypad and programming keys.
Q8: Is the 20BP140A3ANNANC0 still manufactured?
No. Rockwell Automation lists the PowerFlex 700 20B as discontinued on June 1, 2023.
