Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Series | PowerFlex 700 |
| Catalog Number | 20BP170A0ANNANC1 |
| Product Type | DC Input AC Drive |
| Input Voltage | 540 VDC, precharge |
| Input Phase | 3-phase |
| Output Current | 170 A |
| Normal-Duty Power | 90 kW |
| Heavy-Duty Power | 75 kW |
| Frame Size | Frame 6 |
| Enclosure | IP20 / NEMA/UL Type 1 |
| Human Interface | No HIM; blank plate |
| Control Method | Vector control with 24 VDC I/O |
| Communication | No internal communication module |
| Feedback | Standard incremental encoder |
| Encoder Supply | 12 VDC, 250 mA |
| EMC Filter | EMC filter with common-mode choke |
| Brake IGBT | Without |
| Internal Brake Resistor | No |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Digital Inputs | 6 |
| Digital Outputs | 3 |
| Maximum Output Frequency | 420 Hz |
| Carrier Frequency | 2, 4, 8, or 10 kHz |
| Overload Capacity | 110% for 1 min; 150% for 3 s |
| Efficiency | 97.5% |
| Dimensions (H × W × D) | 850 × 403.9 × 275.5 mm* |
| Weight | 71.44 kg* |
| Country of Origin | USA |
FAQ
FAQ
Q1: What is the 20BP170A0ANNANC1?
The 20BP170A0ANNANC1 is an Allen-Bradley PowerFlex 700 DC-input AC drive for industrial motor speed and torque control.
Q2: What is the input voltage?
It uses a 540 VDC input with precharge.
Q3: What is the rated output current and power?
The drive is rated at 170 A, with 90 kW normal-duty and 75 kW heavy-duty ratings.
Q4: Does this model include a HIM keypad?
No. The 20BP170A0ANNANC1 is supplied with no HIM and a blank plate.
Q5: Does it support encoder feedback?
Yes. This configuration includes standard incremental encoder feedback with a 12 VDC, 250 mA encoder supply.
Q6: Does it have an internal communication module?
No. Rockwell specifies no internal communication module for this catalog number.
Q7: Does the drive include a braking resistor?
No. It has no brake IGBT and no internal brake resistor.
Q8: What are the dimensions and weight?
A commonly published reference for this exact model is 850 × 403.9 × 275.5 mm with a weight of 71.44 kg. These figures should be verified against the applicable PowerFlex 700 Frame 6 dimensional drawing before final installation planning.
