Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Series | PowerFlex 700 |
| Catalog Number | 20BR365U0ANNNND0 |
| Product Type | DC Input AC Drive |
| DC Input Voltage | 650 VDC |
| Precharge | Yes |
| Rated Output Current | 365 A |
| Normal-Duty Power | 220 kW / 300 HP |
| Heavy-Duty Power | 180 kW / 250 HP |
| Frame Size | Frame 8 |
| Enclosure | IP00 / NEMA/UL Type Open |
| Human Interface | No HIM / Blank Plate |
| Control Method | Vector Control with 120 VAC I/O |
| Communication | No internal communication module |
| Feedback | No feedback |
| EMC Filter | Without CE-compliant filter |
| Brake IGBT | No |
| Drive-Mounted Brake Resistor | No |
| PWM Carrier Frequency | 2 kHz |
| Ambient Temperature Rating | 40 °C |
| Continuous Output Current | 365 A |
| 1-Minute Output Current | 402 A |
| 3-Second Output Current | 548 A |
| DC Input Current | Approx. 410 A |
| DC Input Power | Approx. 265 kW |
| Fuse | 800 A class, depending on protection configuration |
| Dimensions (H × W × D) | Approx. 2283.7 × 757.8 × 254.6 mm* |
| Drive Weight | Approx. 384 kg* |
| Drive & Packaging Weight | Approx. 431 kg |
FAQ
FAQ
Q1: What is the 20BR365U0ANNNND0?
It is an Allen-Bradley PowerFlex 700 high-power DC-input AC drive for large industrial motor applications.
Q2: What is the DC input voltage?
This PowerFlex 700 configuration belongs to the 650 VDC input with precharge family.
Q3: What is the rated output current?
The rated continuous output current is 365 A. The drive can provide 402 A for 1 minute and 548 A for 3 seconds under the specified conditions.
Q4: What is the motor power rating?
The 20BR365 is rated at approximately 300 HP normal duty and 250 HP heavy duty. Rockwell’s technical data lists the corresponding Frame 8 20BR365 rating at 365 A.
Q5: What enclosure does this model use?
It uses an IP00 / NEMA/UL Type Open configuration. It must therefore be installed in a suitable protective cabinet or enclosure. Rockwell’s Frame 8 documentation distinguishes this from the IP20/NEMA Type 1 version.
Q6: Does it include a HIM keypad?
No. The U0 configuration is supplied without a factory-installed HIM, using a blank plate.
Q7: Does it have communication, feedback, or braking hardware?
The 20BR365U0ANNNND0 configuration is specified without an internal communication module and without feedback. It also does not include a brake IGBT or drive-mounted brake resistor.
Q8: What are the dimensions and weight?
The Frame 8 reference dimensions are approximately 2283.7 × 757.8 × 254.6 mm, with a drive weight of approximately 384 kg and a drive-and-packaging weight of approximately 431 kg.
