Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Product Type | Variable Frequency AC Drive |
| Product Model | 20F11NB9P6JA0NNNNN |
| Product Series | PowerFlex 753 / PowerFlex 750-Series |
| Drive Type | Air-Cooled AC Drive with Embedded I/O |
| Input Voltage | 240 VAC class (208 VAC compatible), 3-phase |
| Output Current | 9.6 A |
| Normal-Duty Rating | 3 HP (2.2 kW) |
| Heavy-Duty Rating | 2 HP (1.5 kW) |
| Frame Size | Frame 2 |
| Enclosure | IP20/IP00, NEMA/UL Open Type |
| Input Type | AC input with precharge and DC terminals |
| EMC Filtering | Filtered |
| CM Jumper | Installed |
| Dynamic Braking | Internal dynamic-braking transistor |
| Human Interface Module (HIM) | Blank; no HIM included |
| Cooling | Forced-air cooling |
| Dimensions (L × W × H) | 140 × 35 × 145 mm (provided dimensions; verify against the manufacturer’s mechanical drawing before installation) |
| Weight | 2.5 kg (provided value; verify for the exact configuration) |
| Battery Included | No |
| Magnet Included | No |
FAQ
FAQ
Q1: What is the Allen-Bradley 20F11NB9P6JA0NNNNN?
A: It is a PowerFlex 753 variable frequency AC drive designed for industrial motor speed control and automation applications.
Q2: What is the input voltage of this drive?
A: It is designed for the 240 VAC class, with three-phase input and compatibility with 208 VAC applications when configured according to manufacturer specifications.
Q3: What are its output current and power ratings?
A: The drive has a listed output current of 9.6 A, with a rating of 3 HP (2.2 kW) for normal-duty applications and 2 HP (1.5 kW) for heavy-duty applications.
Q4: What enclosure type does this model use?
A: It uses an IP20/IP00, NEMA/UL Open Type enclosure. Install it in a suitable electrical cabinet or protected environment.
Q5: Does the drive support dynamic braking?
A: Yes. The specified configuration includes an internal dynamic-braking transistor. An external braking resistor may be needed depending on the application’s stopping requirements.
Q6: Does this model include a Human Interface Module (HIM)?
A: No. The model is specified as a blank configuration without a HIM. A compatible module can be purchased separately if required.
Q7: What are the dimensions and weight of this drive?
A: The supplied specifications list dimensions of 140 × 35 × 145 mm and a weight of 2.5 kg. Verify these figures with the manufacturer’s mechanical drawing and the actual unit before planning mounting or shipping.
Q8: Does the 20F11NB9P6JA0NNNNN include a battery or magnet?
A: The supplied product information indicates that neither a battery nor a magnet is included. Check the full bill of materials if additional accessories are needed.
