Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Single-Axis Servo Drive |
| Model | Allen-Bradley 2198-H003-ERS2 |
| Series | Kinetix 5500 |
| Function | Servo motor speed, torque, and position control |
| Axis Configuration | Single-axis |
| Input Voltage | 190–528 V AC (single-phase or three-phase) |
| Input Frequency | 47–63 Hz |
| Output Current | ~1.4 A continuous / 2.5 A peak |
| Output Power | ~0.2–0.6 kW (depending on supply voltage) |
| Communication | EtherNet/IP |
| Safety Function | Integrated Safety over EtherNet/IP (STO capability) |
| Control Modes | Position, speed, torque, indexing |
| Feedback Support | Encoder-based servo feedback |
| Protection Rating | IP20 (panel mount) |
| Mounting Type | Cabinet / panel installation |
| Cooling Method | Air-cooled |
| Operating Temperature | 0 to 50 °C |
| Dimensions (H × W × D) | ~263 × 55 × 28 mm |
| Weight | ~1.3–3.0 kg |
FAQ
FAQ
Q1. What is the 2198-H003-ERS2 used for?
It is a Kinetix 5500 servo drive used for controlling small servo motors in industrial automation systems such as packaging machines and conveyors.
Q2. How many axes does it support?
It is a single-axis servo drive, controlling one motor.
Q3. What is its power level?
It is a low-power drive, typically in the 0.2–0.6 kW range depending on input voltage and system configuration.
Q4. What type of input power does it support?
It supports 190–528 V AC, either single-phase or three-phase.
Q5. What communication protocol does it use?
It uses EtherNet/IP, allowing integration with Allen-Bradley Logix controllers.
Q6. Does it include safety functions?
Yes, it supports Integrated Safety over EtherNet/IP, including Safe Torque Off (STO).
Q7. Can it operate without a PLC?
It is mainly designed for Logix-based systems but can support limited standalone functionality depending on configuration.
Q8. What are its size and weight?
It is a compact module (~263 × 55 × 28 mm) with a weight of roughly 1.3–3.0 kg depending on revision and accessories.
