Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex 523 |
| Model Number | 25A-D4P0N114 |
| Product Type | AC Variable Frequency Drive (VFD) |
| Drive Type | Adjustable Frequency AC Drive |
| Input Voltage | 380…480V AC |
| Nominal Voltage Class | 480V AC |
| Input Phase | 3-Phase |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0…460V AC |
| Output Frequency Range | 0…500 Hz |
| Rated Output Current | 4.0 A |
| Output Power | 1.5 kW / 2 HP |
| Frame Size | Frame A |
| Enclosure Rating | IP20 / NEMA Open Type |
| EMC Filter | Internal EMC Filter Included |
| Brake IGBT | Included |
| Communication Port | Embedded RS485 / DSI / USB |
| Supported Protocols | Modbus RTU, EtherNet/IP (optional adapter) |
| Digital Inputs | 5 |
| Relay Outputs | 1 Form-C Relay |
| Analog Inputs | 1 |
| Control Methods | V/Hz, Sensorless Vector Control |
| HIM Interface | Standard Integral Keypad |
| Mounting Type | Panel Mount / DIN Rail |
| Cooling Method | Air Cooled |
| Operating Temperature | -20°C to +50°C |
| Certifications | UL, CE, CSA, KC, C-Tick |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 180 × 72 × 172 mm |
| Actual Weight | Approx. 1.1–1.3 kg |
| Typical Applications | Conveyors, Fans, Pumps, Packaging Equipment, OEM Machinery |
FAQ
FAQ
Q1: What is the Allen-Bradley 25A-D4P0N114 used for?
A1: The 25A-D4P0N114 is a PowerFlex 523 AC drive designed for variable-speed control of industrial AC motors in compact automation applications.
Q2: What motor size can the 25A-D4P0N114 control?
A2: The drive supports motors up to 1.5 kW (2 HP) with a rated output current of 4.0 A.
Q3: What input power does the 25A-D4P0N114 require?
A3: The drive operates on 380–480V AC three-phase input power at 50/60 Hz.
Q4: Does the 25A-D4P0N114 include an EMC filter and brake transistor?
A4: Yes. This configuration includes an internal EMC filter and an integrated brake IGBT/chopper.
Q5: What communication capability is included?
A5: The drive includes embedded RS485/DSI communication and a USB programming port, with optional network adapters available for EtherNet/IP and other industrial protocols.
Q6: What are the actual dimensions and weight of the 25A-D4P0N114?
A6: The approximate dimensions are 180 × 72 × 172 mm, and the actual weight is approximately 1.1–1.3 kg.
Q7: Is the 25A-D4P0N114 still an active product?
A7: Yes. Rockwell Automation currently lists the PowerFlex 523 series and this catalog number as Active.
Q8: What are common applications for the 25A-D4P0N114?
A8: Common applications include conveyors, pumps, fans, packaging systems, and OEM machinery requiring compact motor-speed control.
