Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex 525 |
| Model Number | 25B-D043N114 |
| Product Type | AC Variable Frequency Drive (VFD) |
| Drive Type | Adjustable Frequency AC Drive |
| Input Voltage | 380…480V AC |
| Nominal Voltage Class | 480V AC |
| Input Phase | 3-Phase |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0…460V AC |
| Output Frequency Range | 0…500 Hz |
| Rated Output Current | 43 A |
| Normal Duty Rating | 22 kW / 30 HP |
| Heavy Duty Rating | 18.5 kW / 25 HP |
| Frame Size | Frame E |
| Enclosure Rating | IP20 / NEMA Open Type |
| EMC Filter | Integral EMC Filter Included |
| Brake IGBT | Included |
| Dynamic Brake Resistor | Not Included |
| Communication Ports | Embedded EtherNet/IP, RS-485, USB |
| Supported Protocols | EtherNet/IP, Modbus RTU |
| Digital Inputs | 7 |
| Digital Outputs | 4 |
| Analog Inputs | 2 |
| Analog Outputs | 1 |
| Control Methods | V/Hz, Sensorless Vector, Closed Loop Vector, PM Motor Control |
| Safety Features | Safe Torque Off (STO), SIL2 / PLd Cat 3 |
| Mounting Type | Panel Mount |
| Cooling Method | Forced Air Cooling |
| Operating Temperature | -20°C to +50°C |
| Extended Temperature Capability | Up to +70°C with derating |
| Certifications | UL, CE, cUL, KC, RCM |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 300 × 185 × 279 mm |
| Actual Weight | Approx. 12.9–15.7 kg |
| Typical Applications | Conveyors, Pumps, Fans, Mixers, Packaging Machines, OEM Equipment |
FAQ
FAQ
Q1: What is the Allen-Bradley 25B-D043N114 used for?
A1: The 25B-D043N114 is a PowerFlex 525 AC drive designed for industrial motor speed control with integrated networking and safety functions.
Q2: What motor size can the 25B-D043N114 control?
A2: The drive supports 22 kW (30 HP) motors in normal duty applications and 18.5 kW (25 HP) motors in heavy duty applications.
Q3: Does the 25B-D043N114 include EtherNet/IP communication?
A3: Yes. The drive includes embedded EtherNet/IP communication along with RS-485 and USB interfaces.
Q4: Does the drive include Safe Torque Off (STO)?
A4: Yes. Integrated Safe Torque Off functionality is included and certified to SIL2 / PLd Category 3 safety standards.
Q5: Does the 25B-D043N114 include a brake transistor and EMC filter?
A5: Yes. This model includes both an integral brake IGBT/chopper and an internal EMC filter.
Q6: What are the actual dimensions and weight of the 25B-D043N114?
A6: The approximate dimensions are 300 × 185 × 279 mm, and the actual weight is approximately 12.9–15.7 kg depending on packaging and configuration.
Q7: What motor control modes are supported?
A7: The drive supports V/Hz control, Sensorless Vector Control, Closed Loop Vector Control, and Permanent Magnet motor control.
Q8: What are common applications for the 25B-D043N114?
A8: Common applications include conveyors, pumps, fans, mixers, packaging systems, and OEM machinery requiring advanced networked motor control.
