Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley Ultra 3000 High-Voltage Digital Servo Drive |
| Model Number | 2098-DSD-HV100-SE |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Ultra 3000 |
| Product Type | Digital Servo Drive |
| Drive Type | High-Voltage SERCOS Servo Drive |
| Input Voltage | 230–480V AC Three-Phase |
| Input Frequency | 47–63 Hz |
| Continuous Output Current | 23 A (0-peak) |
| Peak Output Current | 46 A (0-peak) |
| Continuous Output Power | 10 kW |
| Communication Interface | SERCOS fiber-optic |
| Control Architecture | Digital servo control loop |
| Feedback Support | Encoder / intelligent feedback systems |
| Auxiliary Power Input | 12/24V DC control supply |
| Internal Shunt Regulator | Integrated |
| Cooling Method | Forced air cooling |
| Mounting Type | Panel mount |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5–95% non-condensing |
| Certifications | CE, UL, CSA |
| Dimensions | Approx. 362 × 244 × 91 mm |
| Weight | Approx. 9–10 kg |
| Lifecycle Status | Discontinued |
| Application | High-power industrial servo motion control systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 2098-DSD-HV100-SE used for?
The 2098-DSD-HV100-SE is an Ultra 3000 high-voltage servo drive used in industrial automation systems for precise motion control in applications such as packaging, robotics, conveyors, and multi-axis machinery.
Q2: What is the power rating of the 2098-DSD-HV100-SE?
It is a 10 kW class servo drive, typically delivering high-power motion control for demanding industrial systems.
Q3: What input voltage does this drive require?
It operates on a 230–480V AC three-phase supply with a frequency range of 47–63 Hz.
Q4: What communication protocol does the 2098-DSD-HV100-SE use?
It uses a SERCOS fiber-optic interface for synchronized multi-axis motion control.
Q5: What is the output current rating?
The drive provides 23 A continuous output and up to 46 A peak output current.
Q6: Is the 2098-DSD-HV100-SE still manufactured?
No, it has been discontinued by Rockwell Automation as part of the Ultra 3000 lifecycle.
Q7: What are the dimensions and weight of the unit?
It is approximately 362 × 244 × 91 mm in size and weighs around 9–10 kg.
Q8: What applications commonly use this servo drive?
It is commonly used in high-performance automation systems such as packaging lines, material handling equipment, printing machines, and coordinated motion platforms.
