Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PowerFlex 527 |
| Model Number | 25C-D1P4N104 |
| Product Type | AC Drive / Variable Frequency Drive (VFD) |
| Rated Power | 0.55 kW / 0.75 HP |
| Input Voltage | 380–480V AC |
| Input Voltage Range | 323–528V AC |
| Input Phase | 3-Phase |
| Output Voltage | 0–460V AC |
| Output Current | 1.4 A |
| Output Frequency | 0–500 Hz |
| Frequency Rating | 50/60 Hz |
| Frame Size | A |
| Control Methods | V/Hz Control, Sensorless Vector Control |
| Communication | Embedded Dual-Port EtherNet/IP |
| Ethernet Features | Device Level Ring (DLR) Support |
| Safety Function | Safe Torque Off (STO) |
| Enclosure Rating | IP20 / NEMA Open Type |
| Mounting Type | DIN Rail or Panel Mount |
| EMC Filter | No Filter |
| Brake IGBT | Not Included |
| Analog Inputs | 2 |
| Analog Outputs | 1 |
| Digital Inputs | 4 |
| Digital Outputs | 2 |
| Operating Temperature | -20°C to 50°C |
| Dimensions (H × W × D) | 160 × 70 × 152 mm |
| Weight | Approx. 1.2 kg / 2.65 lb |
| Compatible Controllers | CompactLogix, ControlLogix, GuardLogix |
FAQ
FAQ
Q1: What is the Allen-Bradley 25C-D1P4N104 used for?
A1: This compact AC drive is designed for controlling small industrial motors in applications such as conveyors, pumps, mixers, and light-duty automation systems.
Q2: What motor size can this drive support?
A2: The 25C-D1P4N104 supports motors rated up to 0.55 kW or 0.75 HP.
Q3: Does this model support EtherNet/IP communication?
A3: Yes. The drive includes embedded dual-port EtherNet/IP communication for seamless integration with Rockwell Automation systems.
Q4: Is this drive suitable for DIN rail installation?
A4: Yes. The unit supports both DIN rail mounting and direct panel mounting, making installation more flexible.
Q5: Does the drive include Safe Torque Off (STO)?
A5: Yes. The built-in Safe Torque Off function enhances machine safety and helps simplify safety circuit design.
Q6: What enclosure protection rating does the 25C-D1P4N104 have?
A6: The drive is rated IP20 / NEMA Open Type and should be installed inside a protective electrical enclosure.
Q7: What are the physical dimensions of the drive?
A7: The dimensions are approximately 160 mm × 70 mm × 152 mm.
Q8: How much does the Allen-Bradley 25C-D1P4N104 weigh?
A8: The drive weighs approximately 1.2 kg (2.65 lb).
