Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PowerFlex 527 |
| Model Number | 25C-D1P4N114 |
| Product Type | AC Drive / Variable Frequency Drive (VFD) |
| Rated Power | 0.4 kW / 0.5 HP |
| Input Voltage | 380–480V AC |
| Input Voltage Range | 323–528V AC |
| Input Phase | 3-Phase |
| Output Voltage | 0–460V AC |
| Output Current | 1.4 A |
| Output Frequency | 0–500 Hz |
| Frequency Rating | 50/60 Hz |
| Frame Size | A |
| Control Methods | V/Hz Control, Sensorless Vector Control, PID Control |
| Communication | Embedded Dual-Port EtherNet/IP |
| Ethernet Features | Device Level Ring (DLR) Support |
| Safety Function | Safe Torque Off (STO) |
| Enclosure Rating | IP20 / NEMA Open Type |
| Mounting Type | Panel Mount or DIN Rail |
| EMC Filter | Included |
| Brake IGBT | Included |
| Analog Inputs | 2 |
| Analog Outputs | 1 |
| Digital Inputs | 4 |
| Digital Outputs | 4 |
| RS-485 Port | 1 |
| Operating Temperature | -20°C to 50°C |
| Dimensions (H × W × D) | 152 × 72 × 172 mm |
| Weight | Approx. 1.26 kg / 2.78 lb |
| Compatible Controllers | CompactLogix, ControlLogix, GuardLogix |
FAQ
FAQ
Q1: What is the Allen-Bradley 25C-D1P4N114 mainly used for?
A1: The 25C-D1P4N114 is designed for industrial motor speed control applications such as conveyors, pumps, fans, and packaging machinery.
Q2: What motor capacity does this drive support?
A2: This model supports motors rated up to 0.4 kW or 0.5 HP in both normal-duty and heavy-duty operation.
Q3: Does the 25C-D1P4N114 include an EMC filter?
A3: Yes. The drive comes with an integrated EMC filter to help reduce electromagnetic interference in industrial installations.
Q4: Is EtherNet/IP communication built into the drive?
A4: Yes. The unit features embedded dual-port EtherNet/IP communication for efficient integration with Rockwell Automation control systems.
Q5: Can the drive be installed on a DIN rail?
A5: Yes. The 25C-D1P4N114 supports both DIN rail mounting and direct panel mounting.
Q6: What safety features are included in this model?
A6: The drive includes Safe Torque Off (STO) functionality, helping improve machine safety and simplify safety compliance.
Q7: What enclosure protection rating does the drive have?
A7: The unit is rated IP20 / NEMA Open Type and is intended for installation inside a protected control cabinet.
Q8: What are the dimensions and weight of the 25C-D1P4N114?
A8: The drive measures 152 mm × 72 mm × 172 mm and weighs approximately 1.26 kg (2.78 lb).
