Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PanelView Plus 400 |
| Model Number | 2711P-B4C20D |
| Product Type | Operator Interface Terminal / HMI |
| Display Size | 3.8 in. |
| Display Type | Color TFT LCD |
| Display Resolution | 320 × 240 Pixels |
| Display Colors | 18-Bit Color Graphics |
| Operator Interface | Keypad and Touchscreen |
| Touchscreen Type | Analog Resistive |
| Function Keys | 8 Programmable Function Keys |
| Communication Ports | Ethernet, RS-232, USB |
| Communication Protocol | EtherNet/IP |
| Ethernet Speed | 10/100 Mbps |
| USB Ports | 1 USB Host Port |
| Power Supply | 18–32V DC |
| Nominal Input Voltage | 24V DC |
| Power Consumption | Approx. 25 W |
| Internal Memory | 64 MB RAM / 64 MB Flash |
| Operating System | Windows CE |
| Backlight Type | LED Backlight |
| Backlight Life | Approx. 50,000 Hours |
| Mounting Type | Panel Mount |
| Enclosure Rating | NEMA Type 12/13, 4X Indoor / IP54, IP65 |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions (H × W × D) | 198 × 290 × 78 mm |
| Weight | Approx. 1.5 kg / 3.3 lb |
| Software Compatibility | FactoryTalk View Machine Edition |
| Product Status | Discontinued / Obsolete |
FAQ
FAQ
Q1: What is the Allen-Bradley 2711P-B4C20D used for?
A1: The 2711P-B4C20D is a PanelView Plus 400 HMI terminal designed for industrial automation applications, including machine monitoring, operator control, and process visualization.
Q2: What type of display does the 2711P-B4C20D feature?
A2: This model includes a 3.8-inch color TFT LCD display with a resolution of 320 × 240 pixels and 18-bit color graphics.
Q3: Does the terminal support both keypad and touchscreen operation?
A3: Yes. The unit combines a resistive touchscreen with programmable keypad controls for flexible machine operation.
Q4: Which communication interfaces are available on the 2711P-B4C20D?
A4: The terminal supports EtherNet/IP communication and includes Ethernet, RS-232, and USB connectivity ports.
Q5: What power input does the 2711P-B4C20D require?
A5: The terminal operates on 18–32V DC input power with a nominal operating voltage of 24V DC.
Q6: What software is used to configure this HMI terminal?
A6: The 2711P-B4C20D is configured using FactoryTalk View Machine Edition software from Rockwell Automation.
Q7: Is the 2711P-B4C20D still manufactured by Allen-Bradley?
A7: No. This model has been discontinued, but refurbished and surplus units are still commonly available through industrial automation suppliers.
Q8: What are the dimensions and weight of the 2711P-B4C20D?
A8: The terminal measures approximately 198 × 290 × 78 mm and weighs about 1.5 kg (3.3 lb).
