Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PanelView Plus 7 Performance |
| Model Number | 2711P-T12W21D8S |
| Product Type | Operator Interface Terminal / HMI |
| Display Size | 12.1 in. Widescreen |
| Display Type | TFT Color LCD |
| Display Resolution | 1280 × 800 Pixels |
| Display Colors | 24-Bit Color Graphics |
| Operator Interface | Touchscreen |
| Touchscreen Type | Analog Resistive |
| Aspect Ratio | Widescreen |
| Communication Ports | Ethernet, RS-232, USB |
| Communication Protocol | EtherNet/IP |
| Ethernet Ports | Dual 10/100 Mbps Ethernet Ports |
| USB Ports | 2 USB Host Ports, 1 USB Device Port |
| Power Supply | 18–32V DC |
| Nominal Input Voltage | 24V DC |
| Power Consumption | Approx. 70 W |
| Internal Memory | 512 MB RAM / 512 MB Flash |
| External Storage | SD Card Slot |
| Operating System | Windows CE 6.0 |
| Backlight Type | LED Backlight |
| Backlight Life | Approx. 50,000 Hours |
| Mounting Type | Panel Mount |
| Special Feature | Factory-Applied Conformal Coating |
| Enclosure Rating | NEMA Type 12/13, 4X Indoor, IP66 |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions (H × W × D) | 311 × 488 × 66 mm |
| Weight | Approx. 4.4 kg / 9.7 lb |
| Software Compatibility | FactoryTalk View Machine Edition |
| Product Status | Discontinued / Obsolete |
FAQ
FAQ
Q1: What is the Allen-Bradley 2711P-T12W21D8S used for?
A1: The 2711P-T12W21D8S is a PanelView Plus 7 Performance HMI terminal designed for industrial automation applications, including machine monitoring, operator control, and real-time process visualization.
Q2: What type of display does the 2711P-T12W21D8S feature?
A2: The terminal features a 12.1-inch widescreen TFT color LCD display with a resolution of 1280 × 800 pixels and 24-bit color graphics.
Q3: Does the 2711P-T12W21D8S support touchscreen operation?
A3: Yes. The unit uses an analog resistive touchscreen designed for reliable industrial operator interaction.
Q4: Which communication interfaces are available on the 2711P-T12W21D8S?
A4: The terminal supports EtherNet/IP communication and includes dual Ethernet ports, RS-232 serial communication, and USB connectivity.
Q5: What does the “S” designation indicate in the model number?
A5: The “S” suffix indicates that the terminal includes a factory-applied conformal coating for additional protection against moisture, dust, and corrosive industrial environments.
Q6: What power input does the 2711P-T12W21D8S require?
A6: The terminal operates on 18–32V DC input power with a nominal operating voltage of 24V DC.
Q7: Is the 2711P-T12W21D8S still manufactured by Allen-Bradley?
A7: No. This model has been discontinued, although refurbished and surplus units are still available through industrial automation suppliers.
Q8: What are the dimensions and weight of the 2711P-T12W21D8S?
A8: The terminal measures approximately 311 × 488 × 66 mm and weighs about 4.4 kg (9.7 lb).
