Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley PanelView Plus 600 Mono |
| Model Number | 2711P-T6M5A |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PanelView Plus 600 |
| Display Size | 5.7 inches |
| Display Type | Monochrome LCD Display |
| Resolution | 320 × 240 pixels |
| Input Type | Keypad Input |
| Keypad Type | Function Key Keypad |
| Communication Ports | DH-485, RS-232, USB |
| Power Supply | 85–264V AC |
| Operating System | Windows CE |
| Memory | 64 MB RAM / 64 MB Flash |
| Mounting Type | Panel Mount |
| Enclosure Rating | NEMA 12, 13, 4X / IP65 (Front) |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions | Approx. 212 × 290 × 112 mm |
| Cutout Dimensions | Approx. 167 × 220 mm |
| Weight | Approx. 1.2 kg |
| Application | Industrial HMI and Machine Control Interface |
FAQ
FAQ
Q1: What is the Allen-Bradley 2711P-T6M5A used for?
The 2711P-T6M5A is a PanelView Plus 600 monochrome HMI terminal designed for industrial machine control, process monitoring, and operator interface applications.
Q2: Does the 2711P-T6M5A use a touchscreen interface?
No, this model uses a keypad input interface instead of a touchscreen, making it suitable for operators who prefer physical control buttons.
Q3: What type of display does the 2711P-T6M5A have?
The terminal features a 5.7-inch monochrome LCD display with a resolution of 320 × 240 pixels.
Q4: What communication interfaces are available on the 2711P-T6M5A?
The unit supports DH-485, RS-232 serial communication, and USB connectivity for integration with industrial automation systems.
Q5: What power input does the 2711P-T6M5A require?
The terminal operates on an AC power supply range of 85–264V AC.
Q6: Which software is commonly used with the 2711P-T6M5A?
FactoryTalk View Machine Edition is commonly used for configuration, programming, and operation of this HMI terminal.
Q7: What are the dimensions and weight of the 2711P-T6M5A?
The approximate dimensions are 212 × 290 × 112 mm, and the unit weighs about 1.2 kg.
Q8: Is the 2711P-T6M5A suitable for industrial environments?
Yes, the terminal is designed for industrial use and includes NEMA 12, 13, 4X and IP65 front-panel protection ratings for durability in harsh environments.
