Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley CompactLogix 5380 |
| Model Number | 5069-L306ER |
| Controller Type | Standard CompactLogix Ethernet Controller |
| Application Memory | 0.6 MB |
| Non-volatile Memory | SD card support (1784-SD / SDHC options) |
| Communication Ports | 2 × Ethernet (10/100/1000 Mbps), 1 × USB |
| Max I/O Modules | Up to 8 Compact 5000 I/O modules |
| Ethernet/IP Nodes | Up to 16 nodes |
| Supported Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Motion Control | Not supported (0 axes) |
| Power Supply | 18–32V DC |
| Power Consumption | Approx. 450 mA @ 24V DC |
| Backplane Communication | High-speed Compact 5000 backplane |
| Mounting Type | DIN rail / backplane integrated |
| Dimensions | 138 × 22 × 105 mm (H × W × D) |
| Weight | Approx. 0.175 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Safety Rating | Up to SIL2 / PLe (system dependent) |
FAQ
FAQ
Q1. What is the 5069-L306ER used for?
It is a CompactLogix 5380 PLC used for machine control and industrial automation applications.
Q2. How much memory does it have?
It provides 0.6 MB of user application memory for control programs.
Q3. How many I/O modules can it support?
It supports up to 8 Compact 5000 I/O modules.
Q4. What communication options are available?
It has two Gigabit Ethernet ports and one USB port for programming and diagnostics.
Q5. Does it support motion control?
No, this model does not support motion axes.
Q6. What programming languages are supported?
It supports Ladder Logic, Structured Text, Function Block Diagram, and Sequential Function Chart.
Q7. Can it run in redundant systems?
No, this specific model does not support redundancy.
Q8. What type of industrial applications is it best suited for?
It is designed for small to medium automation systems requiring high-speed Ethernet communication and modular I/O expansion.
