Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley CompactLogix 5380 |
| Model Number | 5069-L310ERM |
| Controller Type | Standard Motion-enabled CompactLogix Controller |
| Application Memory | 1 MB |
| Communication Ports | 2 × Ethernet (1 Gb), 1 × USB |
| EtherNet/IP Nodes | Up to 24 nodes |
| Integrated Motion Control | Up to 4 axes (CIP Motion over EtherNet/IP) |
| I/O Capacity | Up to 8 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | Approx. 450 mA @ 24V DC |
| Backplane System | Compact 5000 high-speed backplane |
| Isolation | 300V continuous (Ethernet ports non-isolated) |
| Dimensions | 136.81 × 98.1 × 123 mm (W × D × H) |
| Weight | Approx. 0.77 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
FAQ
FAQ
Q1. What is the main function of the 5069-L310ERM?
It is a CompactLogix controller designed for machine automation with integrated motion control capability.
Q2. How much memory does it provide?
It has 1 MB of application memory for control programs.
Q3. How many motion axes does it support?
It supports up to 4 integrated motion axes via EtherNet/IP CIP Motion.
Q4. How many I/O modules can be connected?
It supports up to 8 Compact 5000 I/O modules.
Q5. What communication interfaces are available?
It includes two Gigabit Ethernet ports and one USB port for programming and diagnostics.
Q6. What software is used for configuration?
It is programmed using Studio 5000 Logix Designer.
Q7. What is its typical physical size and weight?
It measures 136.81 × 98.1 × 123 mm and weighs approximately 0.77 kg.
Q8. What type of applications is it best suited for?
It is used in compact machines requiring coordinated motion control, sequencing, and high-speed industrial networking.
