Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley CompactLogix 5380 |
| Model Number | 5069-L320ER |
| Controller Type | Standard CompactLogix Ethernet Controller |
| Application Memory | 2 MB |
| Processor | Quad-core industrial processor |
| Communication Ports | 2 × Ethernet (1 Gb), 1 × USB |
| EtherNet/IP Nodes | Up to 40 nodes |
| I/O Capacity | Up to 16 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | Approx. 1.5 A @ 24V DC (system dependent) |
| Non-volatile Memory | SD card support (1784-SD series) |
| Isolation | 300V continuous (no isolation between Ethernet ports) |
| Dimensions | 136.81 × 123 × 98.1 mm (W × H × D) |
| Weight | Approx. 0.175–0.68 kg (variant dependent) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
FAQ
FAQ
Q1. What is the 5069-L320ER used for?
It is a CompactLogix 5380 PLC used for industrial automation control in medium to large machine systems.
Q2. How much memory does it have?
It provides 2 MB of application memory for control programs.
Q3. How many I/O modules can it support?
It supports up to 16 Compact 5000 I/O modules.
Q4. How many Ethernet nodes does it support?
It supports up to 40 EtherNet/IP nodes for networked devices.
Q5. What communication ports are available?
It includes two Gigabit Ethernet ports and one USB port.
Q6. What software is used for programming?
It is programmed using Studio 5000 Logix Designer.
Q7. Is motion control supported in this model?
No, this is a standard controller without integrated motion capability.
Q8. What kind of applications is it best suited for?
It is commonly used in packaging, material handling, and general machine automation requiring fast Ethernet communication and moderate I/O expansion.
