Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley CompactLogix 5380 |
| Model Number | 5069-L320ERM |
| Controller Type | Motion-enabled CompactLogix Ethernet Controller |
| Application Memory | 2 MB |
| Processor | Quad-core industrial processor |
| Communication Ports | 2 × Ethernet (1 Gb), 1 × USB |
| EtherNet/IP Nodes | Up to 40 nodes |
| Integrated Motion Control | Up to 8 axes (CIP Motion over EtherNet/IP) |
| I/O Capacity | Up to 16 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | Approx. 450 mA @ 24V DC (system dependent) |
| Non-volatile Memory | SD card support |
| Isolation | 300V continuous (no isolation between Ethernet ports) |
| Dimensions | 136.81 × 123 × 98.1 mm |
| Weight | Approx. 3 kg (variant dependent packaging data varies by source) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Functional Capability | High-speed motion + standard control integration |
FAQ
FAQ
Q1. What is the 5069-L320ERM used for?
It is a CompactLogix 5380 controller designed for machine automation with integrated motion control capabilities.
Q2. How much memory does it have?
It provides 2 MB of application memory for control logic and programs.
Q3. How many motion axes does it support?
It supports up to 8 axes of integrated CIP Motion over EtherNet/IP.
Q4. How many I/O modules can be connected?
It supports up to 16 Compact 5000 I/O modules.
Q5. What communication ports are available?
It includes two Gigabit Ethernet ports and one USB port.
Q6. What software is used for programming?
It is programmed using Studio 5000 Logix Designer.
Q7. What makes the “ERM” version different?
ERM indicates motion capability is enabled, allowing coordinated servo and motion control functions.
Q8. What types of applications is it best suited for?
It is commonly used in packaging, robotics, assembly machines, and other systems requiring synchronized motion and high-speed industrial networking.
