Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley Compact GuardLogix 5380 |
| Model Number | 5069-L320ERS2 |
| Controller Type | Safety Controller (GuardLogix) |
| Safety Rating | SIL 2 / PLd capable |
| Standard Memory | 2 MB |
| Safety Memory | 1 MB |
| Total Memory | 3 MB (standard + safety) |
| Processor | High-performance industrial processor |
| Communication Ports | 2 × Ethernet (1 Gb), 1 × USB |
| EtherNet/IP Nodes | Up to 40 nodes |
| Integrated Motion Control | Not supported |
| I/O Capacity | Up to 16 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | System dependent (~1 A @ 24V DC typical) |
| Non-volatile Memory | SD card support |
| Dimensions | 136.81 × 123 × 98.1 mm (W × H × D) |
| Weight | Approx. 0.9–1.1 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Product Status | Active |
FAQ
FAQ
Q1. What is the main purpose of the 5069-L320ERS2?
It is a safety PLC used for machine control systems requiring integrated functional safety.
Q2. What safety level does it support?
It supports SIL 2 and PLd safety standards for industrial applications.
Q3. Does it support motion control?
No, this model does not include integrated motion capabilities.
Q4. How much memory does it have?
It provides 2 MB standard memory and 1 MB safety memory.
Q5. How many I/O modules can it support?
It supports up to 16 Compact 5000 I/O modules.
Q6. What communication interfaces are available?
It includes dual Gigabit Ethernet ports and one USB port.
Q7. What software is used for programming?
It is programmed using Studio 5000 Logix Designer.
Q8. What type of applications is it used for?
It is used in safety-critical automation such as packaging machines, conveyors, robotics cells, and general machine safety systems.
