Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley CompactLogix 5380 |
| Model Number | 5069-L340ER |
| Controller Type | High-performance CompactLogix Ethernet Controller |
| Application Memory | 4 MB |
| Processor | Quad-core industrial processor |
| Communication Ports | 2 × Ethernet (1 Gb), 1 × USB 2.0 |
| EtherNet/IP Nodes | Up to 55–90 nodes (system dependent) |
| Integrated Motion Control | Not supported |
| I/O Capacity | Up to 31 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | Approx. 8.5 W (typical system dependent) |
| Non-volatile Memory | SD card support |
| Isolation | 300V continuous (no isolation between Ethernet ports) |
| Dimensions | 136.81 × 123 × 98.1 mm |
| Weight | Approx. 0.175 kg (175 g) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
FAQ
FAQ
Q1. What is the 5069-L340ER used for?
It is a high-performance CompactLogix PLC used for industrial automation and machine control systems.
Q2. How much memory does it have?
It provides 4 MB of application memory for control programs.
Q3. Does it support motion control?
No, this model does not support integrated motion control.
Q4. How many I/O modules can it support?
It supports up to 31 Compact 5000 I/O modules.
Q5. How many Ethernet ports does it have?
It includes 2 Gigabit Ethernet ports and 1 USB port for programming and diagnostics.
Q6. How many EtherNet/IP nodes are supported?
It supports approximately 55 to 90 nodes depending on system configuration.
Q7. What software is used for programming?
It is programmed using Studio 5000 Logix Designer.
Q8. What is the weight of the controller?
Approximately 0.175 kg (175 g).
