Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley PanelView Plus 7 Standard |
| Model Number | 2711P-T7C21D8S |
| Display Type | 6.5-inch TFT color LCD (touchscreen) |
| Resolution | 640 × 480 pixels (VGA, 18-bit color) |
| Input Method | Analog resistive touchscreen |
| Communication Ports | 1 × Ethernet (10/100 Mbps), 2 × USB |
| Power Supply | 18–30V DC (24V DC nominal) |
| Power Consumption | Up to ~35–50 W |
| Processor | Embedded industrial processor |
| Memory | 512 MB RAM / 512 MB storage (approx. 80 MB user memory) |
| Operating System | Windows CE |
| Software | FactoryTalk View Machine Edition |
| Enclosure Rating | NEMA 4X / 12 / 13, IP66 (front panel) |
| Mounting Type | Panel mount |
| Dimensions | 170 × 212 × 56.5 mm (W × H × D) |
| Weight | Approx. 0.85 kg |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Relative Humidity | 5% to 95% non-condensing |
FAQ
FAQ
Q1. What is the 2711P-T7C21D8S used for?
It is an industrial HMI used for machine monitoring, visualization, and operator control in automation systems.
Q2. What display does this model use?
It uses a 6.5-inch TFT color touchscreen with VGA resolution.
Q3. What communication interfaces are available?
It includes Ethernet and USB ports for system connectivity.
Q4. What is the power requirement?
It operates on 18–30V DC, typically 24V DC nominal.
Q5. Which software is used for configuration?
FactoryTalk View Machine Edition is used for programming and runtime applications.
Q6. Is this model suitable for harsh environments?
Yes, it has NEMA 4X / IP66-rated front protection for industrial environments.
Q7. What is the memory capacity of the device?
It provides 512 MB RAM and 512 MB storage memory with additional user memory available.
Q8. What is its typical physical size and weight?
It measures 170 × 212 × 56.5 mm and weighs about 0.85 kg.
