Allen Bradley 5094-MB Mounting Base Unit

FAQ

Q1: What is the Allen-Bradley 5094-MB used for?
The 5094-MB is a FLEX 5000 mounting base used to mechanically mount and electrically connect FLEX 5000 I/O modules within a distributed automation system.

Q2: Does the 5094-MB contain electronics or I/O functions?
No, the 5094-MB is a passive base unit that provides physical support and backplane connectivity for FLEX 5000 modules.

Q3: Which systems are compatible with the 5094-MB?
It is designed for Allen-Bradley FLEX 5000 EtherNet/IP distributed I/O systems used with CompactLogix and ControlLogix controllers.

Q4: How is the 5094-MB installed?
The base mounts directly onto a standard DIN rail and allows FLEX 5000 modules to snap into place.

Q5: Does the 5094-MB distribute power between modules?
Yes, it supports internal distribution of MOD power and SA power across connected FLEX 5000 modules.

Q6: What is the purpose of the integrated backplane connection?
The integrated backplane enables communication and power transfer between connected FLEX 5000 modules and the network adapter.

Q7: What are the dimensions and weight of the 5094-MB?
The approximate dimensions are 153 × 22 × 106 mm, and the mounting base weighs about 0.12–0.18 kg.

Q8: What applications commonly use the 5094-MB?
It is commonly used in distributed machine automation, process control, material handling, packaging, and industrial Ethernet I/O systems.
