Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley 1771 I/O System |
| Model Number | FM1771 |
| Product Type | Filler Module (Blank Slot Insert) |
| Function | Occupies unused slots in 1771 PLC I/O chassis |
| System Compatibility | PLC-5 / 1771 Universal I/O Chassis |
| Electrical Function | None (no signal processing or I/O capability) |
| Backplane Connection | No active electrical connection |
| Primary Purpose | Mechanical support, airflow management, EMI shielding |
| Installation Type | Plug-in rack module |
| Material | Industrial-grade plastic / PCB frame |
| Maintenance Role | Prevents dust ingress and maintains chassis integrity |
| Operating Temperature | 0°C to 60°C (system dependent) |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 254 × 25 × 51 mm |
| Weight | Approx. 0.1–0.2 kg |
FAQ
FAQ
Q1. What is the FM1771 used for?
It is used to fill empty slots in Allen-Bradley 1771 PLC chassis.
Q2. Does the FM1771 perform any control function?
No. It has no electrical or control functionality.
Q3. Why is a filler module needed in a PLC rack?
It helps maintain proper airflow, EMI shielding, and mechanical stability.
Q4. Can I operate a PLC rack without FM1771 installed?
It is not recommended, as empty slots may affect cooling and protection.
Q5. Which PLC systems use this module?
It is used in PLC-5 systems with 1771 I/O chassis.
Q6. Is FM1771 still manufactured?
No, it is a discontinued legacy component, still available through surplus markets.
Q7. Does it require wiring or configuration?
No wiring or configuration is required.
Q8. What is the weight of FM1771?
Approximately 0.1–0.2 kg, depending on revision and supplier packaging.
