Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PLC-5 Accessories |
| Model Number | 1784-CP10 |
| Product Type | PLC Programming Communication Cable |
| Cable Type | RS-232 Serial Communication Cable |
| Communication Protocol | DF1 Full Duplex |
| PC Connector | DB9 Male Connector |
| PLC Connector | DB25 Male Connector |
| Cable Length | 10 ft (3 m) |
| Supported Communication Speed | Up to 19.2 kbps |
| Default Baud Rate | 9600 bps |
| Compatible Controllers | PLC-5, SLC 5/01, SLC 5/02, SLC 5/03, SLC 5/04, SLC 5/05 |
| Compatible Software | RSLogix 5, RSLogix 500, RSLinx |
| Connection Type | Null Modem Serial Connection |
| Shielding | Shielded Industrial Cable |
| Jacket Material | Industrial PVC |
| Mounting Style | External Cable Connection |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE |
| Lifecycle Status | Discontinued |
| Replacement Availability | No Direct Rockwell Replacement |
| Dimensions | Approx. 3 m Cable Length |
| Weight | Approx. 0.18 – 0.25 kg |
| Typical Applications | PLC Programming, Controller Communication, Industrial Automation Maintenance |
FAQ
FAQ
Q1: What is the Allen-Bradley 1784-CP10 used for?
A1: The 1784-CP10 is a serial communication cable used for connecting a PC to Allen-Bradley PLC-5 and SLC controllers for programming, troubleshooting, and data transfer.
Q2: What connectors are included on the 1784-CP10 cable?
A2: The cable includes a DB9 male connector for the PC side and a DB25 male connector for the PLC side.
Q3: Which Allen-Bradley controllers are compatible with the 1784-CP10?
A3: The cable is compatible with PLC-5 controllers and many SLC 5/01 through SLC 5/05 processors that support RS-232 DF1 serial communication.
Q4: What communication protocol does the 1784-CP10 use?
A4: The cable uses DF1 Full Duplex serial communication over an RS-232 connection for controller programming and diagnostics.
Q5: What is the cable length of the 1784-CP10?
A5: The standard cable length is approximately 10 feet, or about 3 meters.
Q6: Is the 1784-CP10 still available from Rockwell Automation?
A6: No. Rockwell Automation discontinued the 1784-CP10 on December 31, 2019, and no direct replacement has been announced.
Q7: Can USB-to-Serial adapters be used with the 1784-CP10?
A7: Yes. Many technicians use USB-to-serial adapters together with the 1784-CP10 cable when connecting modern laptops to legacy PLC systems, although adapter compatibility can vary.
Q8: What are the common applications of the 1784-CP10?
A8: Common applications include PLC programming, uploading and downloading controller logic, diagnostics, maintenance troubleshooting, and legacy Allen-Bradley system communication.
