Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley VPL Series (Kinetix VP Low Inertia Servo Motor) |
| Model Number | VPL-B0753E-CK12AA |
| Product Type | Low Inertia Rotary Servo Motor |
| Rated Voltage | 400 V AC |
| Rated Torque | 2.39 Nm |
| Peak Torque | 7.17 Nm |
| Rated Speed | 3000 rpm |
| Maximum Speed | 5000 rpm |
| Frame Size | 75 mm |
| Motor Stack Length | 3 (medium stack) |
| Feedback Device | 24-bit absolute multi-turn digital encoder |
| Brake | No brake |
| Shaft Type | Keyed shaft with shaft seal |
| Enclosure Rating | IP65 |
| Mounting Type | Metric flange |
| Connector Type | Single cable (hybrid power and feedback) |
| Continuous Output Power | Approx. 0.75 kW |
| Cooling Method | Natural convection |
| Operating Temperature | 0°C to 40°C |
| Application Type | High-performance motion control, packaging, robotics |
| Dimensions | Approx. 180 × 75 × 75 mm |
| Weight | Approx. 2.8–3.5 kg |
FAQ
FAQ
Q1. What is the VPL-B0753E-CK12AA used for?
It is used in high-performance motion control applications such as packaging machines, robotics, and automated assembly systems.
Q2. What type of motor is it?
It is a low inertia AC servo motor from the Kinetix VP (VPL) series.
Q3. Does it include a brake?
No, this model does not include a holding brake.
Q4. What feedback system does it use?
It uses a high-resolution 24-bit absolute multi-turn encoder.
Q5. What is the rated speed?
The rated speed is 3000 rpm, with a maximum speed of up to 5000 rpm.
Q6. What is the protection rating?
It has an IP65 enclosure rating, suitable for industrial environments.
Q7. What type of cable connection does it use?
It uses a single hybrid cable for both power and feedback.
Q8. What is the weight of the motor?
Approximately 2.8–3.5 kg, depending on configuration and options.
