Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley VPL Series (Kinetix VP Low Inertia Servo Motor) |
| Model Number | VPL-B0753M-PK12AS |
| Product Type | Low Inertia Rotary Servo Motor |
| Rated Voltage | 400 V AC |
| Rated Torque | 2.39 Nm |
| Peak Torque | 7.17 Nm |
| Rated Speed | 3000 rpm |
| Maximum Speed | 6000 rpm |
| Frame Size | 75 mm |
| Motor Stack Length | 3 (medium stack) |
| Feedback Device | 24-bit absolute multi-turn digital encoder |
| Brake | Yes (24 V DC holding brake) |
| Shaft Type | Keyed shaft with shaft seal |
| Enclosure Rating | IP65 |
| Mounting Type | Metric flange |
| Connector Type | Single cable (hybrid power and feedback) |
| Continuous Output Power | Approx. 0.75 kW |
| Cooling Method | Natural convection |
| Operating Temperature | 0°C to 40°C |
| Application Type | High-speed precision motion control, robotics, packaging |
| Dimensions | Approx. 200 × 75 × 75 mm |
| Weight | Approx. 3.0–3.8 kg |
FAQ
FAQ
Q1. What is the VPL-B0753M-PK12AS used for?
It is used in precision automation systems such as robotics, packaging, and high-speed assembly applications.
Q2. What type of motor is it?
It is a low inertia AC servo motor from the Allen-Bradley Kinetix VP (VPL) series.
Q3. Does it include a brake?
Yes, it includes a 24 V DC holding brake for position holding when power is removed.
Q4. What feedback device is used?
It features a 24-bit absolute multi-turn encoder for high-resolution positioning.
Q5. What is the rated and maximum speed?
Rated speed is 3000 rpm, with a maximum speed up to 6000 rpm.
Q6. What is the shaft configuration?
It has a keyed shaft with a shaft seal for improved mechanical coupling and protection.
Q7. What is the enclosure rating?
It is rated IP65, suitable for industrial environments.
Q8. What is the weight of the motor?
Approximately 3.0–3.8 kg, depending on configuration and options.
