Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Modbus Master/Slave Communication Module |
| Model Number | MVI56-MCM |
| Manufacturer | ProSoft Technology (Rockwell Automation Encompass Partner) |
| Platform | Allen-Bradley ControlLogix (1756 chassis) |
| Module Type | Single-slot Modbus RTU/ASCII communication module |
| Communication Protocol | Modbus RTU / Modbus ASCII (Master & Slave) |
| Serial Ports | 2 × isolated serial ports (RS-232 / RS-485 configurable) |
| Backplane Current | ~800 mA @ 5 V DC |
| Slot Requirement | 1 × 1756 ControlLogix slot |
| Data Capacity | Up to 10,000 × 16-bit registers |
| Configuration Tool | Studio 5000 (RSLogix 5000) + Add-On Instruction (AOI) |
| Diagnostics | LED status indicators + controller tag diagnostics |
| Data Transfer Method | Backplane memory mapping (I/O image) |
| Programming Requirement | No external programming required (AOI-based) |
| Dimensions | Approx. 145 × 35 × 140 mm |
| Weight | Approx. 0.3 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Function | Modbus RTU/ASCII communication gateway module |
| System Role | Interface between ControlLogix PLC and Modbus devices |
FAQ
FAQ
Q1: What is the MVI56-MCM module?
It is a ProSoft ControlLogix communication module that provides Modbus RTU and ASCII Master/Slave functionality for Allen-Bradley PLC systems.
Q2: Which PLC platform does it support?
It is designed for the Allen-Bradley ControlLogix platform using the 1756 chassis.
Q3: How many serial ports does it have?
It has two isolated serial ports, configurable as RS-232 or RS-485.
Q4: What protocols does it support?
It supports Modbus RTU and Modbus ASCII in both Master and Slave modes.
Q5: How does it communicate with the PLC?
It exchanges data through the ControlLogix backplane using I/O memory mapping and Add-On Instructions (AOI).
Q6: Does it require special programming?
No, it uses pre-built AOI blocks and configuration in Studio 5000 without custom firmware programming.
Q7: What is it commonly used for?
It is widely used for connecting Modbus field devices such as energy meters, VFDs, analyzers, and sensors into ControlLogix systems.
Q8: Why is it still widely used?
Because it provides a stable, simple, and well-supported way to integrate Modbus RTU networks into Rockwell Automation ControlLogix platforms.
