Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Modbus Master/Slave Enhanced Communication Module (Reduced Data Block) |
| Model Number | MVI56-MCMR |
| Manufacturer | ProSoft Technology (Rockwell Automation Encompass Partner) |
| Platform | Allen-Bradley ControlLogix (1756 chassis) |
| Module Type | Single-slot Modbus RTU/ASCII communication module |
| Communication Protocol | Modbus RTU / Modbus ASCII (Master & Slave) |
| Serial Ports | 2 × isolated serial ports (RS-232 / RS-485 configurable) |
| Backplane Current | ~800 mA @ 5 V DC |
| Slot Requirement | 1 × 1756 ControlLogix slot |
| Data Capacity | Up to ~5000 × 16-bit registers (reduced data block architecture) |
| Configuration Tool | Studio 5000 (AOI) + ProSoft Configuration Builder (PCB) |
| Diagnostics | LED status display + controller tag diagnostics |
| Data Transfer Method | ControlLogix backplane memory mapping (I/O image) |
| Ethernet Port | 10/100 Mbps configuration/diagnostic port (on E-series variants) |
| Programming Requirement | AOI-based (no firmware coding required) |
| Dimensions | Approx. 145 × 35 × 140 mm |
| Weight | Approx. 0.3 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Function | Modbus RTU/ASCII gateway module with reduced data block optimization |
| System Role | High-efficiency Modbus interface for ControlLogix systems |
FAQ
FAQ
Q1: What is the MVI56-MCMR module?
It is a ProSoft ControlLogix communication module that enables Modbus RTU/ASCII Master/Slave communication with reduced data block architecture to improve efficiency.
Q2: What is the difference between MVI56-MCM and MVI56-MCMR?
The MCMR version uses a reduced data block design, which lowers backplane traffic and improves performance in remote or bandwidth-limited systems.
Q3: Which PLC platform does it support?
It is designed for Allen-Bradley ControlLogix systems using the 1756 chassis.
Q4: How many serial ports does it have?
It has two isolated serial ports, configurable as RS-232 or RS-485.
Q5: What communication protocols are supported?
It supports Modbus RTU and Modbus ASCII in both Master and Slave modes.
Q6: How does it communicate with the PLC?
It exchanges data via the ControlLogix backplane using I/O mapping and Add-On Instructions (AOI).
Q7: What is it typically used for?
It is used for industrial Modbus integration such as energy meters, VFDs, analyzers, and distributed field devices, especially in larger networks.
Q8: Why use the reduced data block version?
Because it reduces backplane and network overhead, making it more suitable for remote racks, large polling systems, or constrained communication environments.
