Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | ProSoft inRAx Communication Module |
| Model Number | MVI69-MNET |
| Product Type | Modbus TCP/IP Client/Server Communication Module |
| Platform Compatibility | Allen-Bradley CompactLogix / MicroLogix 1500 (1769 backplane) |
| Function | Enables Modbus TCP/IP communication between PLC and Ethernet devices |
| Protocol Support | Modbus TCP/IP (Client & Server modes) |
| Ethernet Port | 1 × 10/100 Mbps RJ45 |
| Slot Requirement | Single-slot 1769 I/O module |
| Data Handling | Internal database mapped to PLC tags |
| Configuration Method | Web-based interface + Add-On Instruction (AOI) |
| Command Capacity | Up to 500 commands (system dependent) |
| Backplane Current | Approx. 800 mA @ 5 VDC |
| Isolation | Ethernet and backplane electrical isolation |
| Diagnostics | LED indicators + embedded web diagnostics |
| Network Features | CIP passthrough support |
| Mounting Type | CompactLogix rack-mounted module |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 137 × 87 × 105 mm |
| Weight | Approx. 0.5–1.2 kg |
FAQ
FAQ
Q1. What is the MVI69-MNET used for?
It is used to connect CompactLogix PLCs to Modbus TCP/IP devices over Ethernet networks.
Q2. What communication protocol does it support?
It supports Modbus TCP/IP in both Client (Master) and Server (Slave) modes.
Q3. How does it connect to the PLC?
It installs in the 1769 backplane and appears as a standard I/O module.
Q4. Does it require programming in ladder logic?
Yes, it uses an Add-On Instruction (AOI) in Studio 5000 for configuration and data handling.
Q5. What is the main advantage of this module?
It simplifies integration of Ethernet-based Modbus devices into CompactLogix systems.
Q6. Can it act as both server and client?
Yes, it supports dual-mode operation (Client and Server).
Q7. What industries use this module?
It is widely used in manufacturing, water treatment, energy, and process automation systems.
Q8. What is the weight of the module?
Approximately 0.5–1.2 kg, depending on revision and packaging.
