Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | ProSoft inRAx Communication Module |
| Model Number | MVI69L-MBS |
| Product Type | Modbus Serial Master/Slave Communication Module |
| Platform Compatibility | Allen-Bradley CompactLogix (1769 backplane) |
| Function | Enables Modbus RTU/ASCII communication between PLC and field devices |
| Protocol Support | Modbus RTU, Modbus ASCII |
| Mode Support | Master and Slave (configurable) |
| Ports | 1 × serial port (RS-232/RS-485 configurable) |
| Slot Requirement | Single-slot 1769 I/O module |
| Data Transfer Method | Internal database mapping to PLC tags |
| Configuration Method | Web-based configuration interface |
| Baud Rate | Up to 115.2 kbps |
| Backplane Current | Approx. 800 mA @ 5 VDC |
| Isolation | Electrical isolation between serial port and backplane |
| Diagnostics | LED indicators + embedded diagnostics web page |
| Mounting Type | CompactLogix rack-mounted module |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 137 × 87 × 105 mm |
| Weight | Approx. 0.5–1.1 kg |
FAQ
FAQ
Q1. What is the MVI69L-MBS used for?
It is used to connect CompactLogix PLCs to Modbus RTU/ASCII devices such as meters, drives, and sensors.
Q2. What protocol does it support?
It supports Modbus RTU and Modbus ASCII in both Master and Slave modes.
Q3. How many serial ports does it have?
It has one configurable serial port supporting RS-232 or RS-485.
Q4. How is it configured?
It is configured through a built-in web interface and integrated into the PLC using standard tag mapping.
Q5. What is its main advantage?
It simplifies integration of Modbus devices into a CompactLogix system without complex ladder logic.
Q6. Does it support both Master and Slave roles?
Yes, it can be configured as either Modbus Master or Slave.
Q7. What PLC systems are compatible?
It is designed for CompactLogix controllers using the 1769 backplane.
Q8. What is the weight of the module?
Approximately 0.5–1.1 kg, depending on configuration and packaging.
