Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | ProSoft inRAx Communication Module |
| Model Number | MVI94-ADM |
| Product Type | ASCII Data Messaging Communication Module |
| Platform Compatibility | Allen-Bradley SLC 500 (1746 backplane) |
| Function | Enables ASCII-based data exchange between PLC and external serial devices |
| Protocol Support | User-defined ASCII / serial messaging |
| Ports | 2 × serial ports (RS-232/RS-485 configurable) |
| Slot Requirement | Single-slot 1746 chassis module |
| Data Handling | Internal buffer memory mapped to PLC files (N, B, etc.) |
| Message Type | Command/response ASCII strings |
| Configuration Method | Text-based configuration file + ladder logic (M0/M1 files) |
| Backplane Current | Approx. 800 mA @ 5.1 VDC |
| Isolation | Serial port electrical isolation |
| Diagnostics | LED status indicators |
| Mounting Type | SLC 500 rack-mounted module |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 145 × 140 × 50 mm |
| Weight | Approx. 0.5–1.5 kg |
FAQ
FAQ
Q1. What is the MVI94-ADM used for?
It is used to enable ASCII-based serial communication between SLC 500 PLCs and external devices such as barcode scanners, printers, or custom equipment.
Q2. What type of data does it handle?
It handles ASCII string-based messaging (command/response communication).
Q3. How does it communicate with the PLC?
It uses SLC data files (M0/M1, N, B files) for data exchange with ladder logic.
Q4. How many serial ports does it have?
It provides two configurable serial ports supporting RS-232 or RS-485.
Q5. What kind of devices can it connect to?
It can connect to barcode readers, weigh scales, printers, and other ASCII-based serial devices.
Q6. Is it plug-and-play?
No, it requires configuration via text files and ladder logic programming.
Q7. What PLC systems are compatible?
It is designed specifically for Allen-Bradley SLC 500 systems using the 1746 chassis.
Q8. What is the weight of the module?
Approximately 0.5–1.5 kg, depending on revision and packaging.
